Specifications
Certifications
Approvals
CE
Dimensions
Gobo Size
19 mm outside, 14 mm image, 1 mm max thickness
Dimensions
10x6.1x16.3"
Electrical
Nput Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Current
147W, 1.9 A @ 120V, 60 Hz
Power and Current
143W, 1.1 A @ 230V, 50 Hz
Optics
Gobos
7 + open (6 metal, 1 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
Beam Angle
21°
Prism
3-facet round, rotation at variable speeds
Construction
Colors
8 + white, split colors, continuous scroll at variable speeds
Controls
DMX Connectors
3-pin XLR
Strobe Rate
0 to 20 Hz
Shipping
Weight
12.6 lbs (5.7 kg)
General
Pan and Tilt
172°/39°
Light Source
1 LED (white) 100W, (4.2 A), 50,000 hours life expectancy
Illuminance
4050 lux @ 2m
Power Linking
4 units @ 120V; 7 units @230V
Control
DMX Channels
8 or 12
