Specifications
Performance
Pan and Tilt
540°/225°
Pan and Tilt Ranges
180°, 360°, 540° pan / 90°, 180°, 225° tilt
Zoom Angle
5° to 27°
Strobe Rate
0 to 20 Hz
Illuminance Narrow (5°)
30,537 lux @ 2 m
Illuminance Wide (27°)
3,390 lux @ 2 m
Audio
DMX Channels
9 or 14
DMX Connectors
3-pin XLR
Electrical
Light Source
7 LEDs (quad-color RGBW) 140 W total (5 A), 50,000 hours life expectancy
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current (120 V)
148 W, 1.2 A @ 120 V, 60 Hz
Power and Current (230 V)
146 W, 0.7 A @ 230 V, 50 Hz
Power Linking
6 units @ 120 V; 12 units @ 230 V
Cable Length
5 ft (1.5 m)
Dimensions
Product Dimensions
14.2" x 10" x 7.41"
Package Dimensions
18.43" x 14.09" x 10.51"
Weight
Product Weight
13.8 lbs
Package Weight
16.53 lbs
Certifications
Approvals
CE, RoHS, FCC
Included Items
Includes
Power cord, Hanging bracket, Quick Reference Guide
Compatibility
Optional Controllers
IRC-6, ILS Command
Recommended Gear Bag
CHS-40 VIP
