Chauvet Pro COLORADOPXLCURVE5 IP65 RGBW Arrayable Batten With 5 Motorized Heads
Chauvet Pro COLORADOPXLCURVE5 IP65 RGBW Arrayable Batten With 5 Motorized Heads
SoundPro Item: 207043 | Part Number: COLORADOPXLCURVE5
Usually ships in 5-7 business days
- Five Independent Motorized Heads Each Deliver 120W RGBW Output With Pan, Tilt, And Zoom Control
- Dual Linear Cool And Warm White Strobe Cells Per Head Provide Eight Separately Controlled Strobe Sections
- Alignment Pins Enable Seamless Side-By-Side Mounting For Consistent Pixel Pitch Across Linked Fixtures
- IP65 Rating Protects Internal Components During Temporary Outdoor And Wet Location Deployments
- Multi-Protocol Support Spans DMX, sACN, And Art-Net Over Rated etherCON And 5-Pin XLR Connections
- Selectable PWM Frequencies Up To 15000 Hz Eliminate Flicker For Broadcast And High-Speed Camera Applications
- RDM Functionality Allows Remote Addressing And Diagnostics Across Distributed Installations
Built for touring professionals and rental companies deploying large-scale stage productions, the COLORado PXL Curve 5 combines weather-resistant construction with advanced motorization that rivals conventional moving heads. Each of the five independent RGBW sections offers 60° of pan and 200° of tilt alongside zoom ranging from tight 8.3° beams to expansive 155.1° wash coverage, creating versatile looks from a single compact batten. Alignment pins ensure seamless side-by-side mounting with consistent spacing across multiple units, critical for achieving uniform pixel-mapped displays on festival stages and theatrical rigs.
The fixture integrates dual linear cool and warm white strobe cells within every head, providing designers with eight individually controlled strobe sections that complement the primary RGBW output. Supporting DMX, sACN, and Art-Net protocols over IP65-rated etherCON and 5-pin XLR connections, the batten adapts to evolving control ecosystems while RDM enables remote addressing across distributed installations. Variable PWM frequencies from 600 Hz to 15,000 Hz eliminate flicker during broadcast and camera work, making this equally suited to live concerts and filmed events requiring high-speed imaging.
