Chauvet Pro COLORADOSOLOBAR1 4-Cell RGBwWL IP65 LED Batten

Chauvet Pro COLORADOSOLOBAR1 4-Cell RGBwWL IP65 LED Batten

SoundPro Item: 146620 | Part Number: COLORADOSOLOBAR1

$1,862.00
$2,138.00 $1,862.00
Your Price Sold out
MSRP: $2,138.00 | MAP: $1,862.00

Usually ships in 5-7 business days

  • IP65 All-Weather Rating With Pressure-Equalizing Gore Valve For Outdoor And Indoor Durability
  • Homogenized Optics Eliminate Hotspots For Seamless Edge-To-Edge Pixel-Mapped Color
  • CRI 95 And High TM-30 Values Deliver Broadcast-Grade Color Fidelity
  • Selectable PWM Up To 25,000 Hz Ensures Flicker-Free Performance On Any Camera Setting
  • Multiple Control Protocols Including DMX, RDM, CRMX, Art-Net, And sACN Across 32 Personalities
  • Integrated Guide Pins And T-Rail Sliding Brackets Simplify Multi-Unit End-To-End Rigging
  • Stowable Glare Shield And Slide-In Filter Slot Provide On-Site Beam Shaping Flexibility
Log in or register for YOUR best price

The Chauvet Pro COLORado Solo Bar 1 is built for lighting designers who need a single fixture to cover cyc work, footlight duty, and traditional batten downlighting without compromise. Its four RGBwWL LED engines deliver over 4,200 lumens with a CRI of 95 and linear color temperature control from 2800 K to 8000 K, giving broadcast and film crews the precision white balancing that camera-critical environments demand. Homogenized optics eliminate the hotspot artifacts common in competing LED battens, producing seamless edge-to-edge color across the full fixture face.

Touring and festival crews benefit from an IP65-rated aluminum diecast housing that handles outdoor exposure, fog, and haze without sacrificing the lightweight profile needed for fast load-ins. Integrated guide pins allow multiple units to align end-to-end quickly, while adjustable sliding brackets fit standard T-rail truss without additional hardware. A stowable glare shield and slide-in filter slot — with CYC, half, stealth, and protective filters included — give the LD on-site control over beam shaping without separate accessories.

For system integrators and production houses, the fixture supports DMX, RDM, Art-Net, sACN, and CRMX across 32 personalities, covering everything from simple 3-channel RGB operation to full 67-channel per-cell control. Ultra-smooth 18-bit dimming with four selectable curves and selectable PWM frequencies up to 25,000 Hz make it flicker-free on any camera shutter setting, while a measured idle noise floor of 5.1 dB(A) keeps it viable in theater and broadcast environments where background noise is a disqualifier.

Downloads

View full details

Specifications

Certifications
IP Rating
IP65, temporary outdoor use, with pressure equalizing M12 GORE valve
Certifications
CE, MET, FCC, UKCA
Noise Level (Idle)
5.1 dB(A) @ 1 m
Noise Level (Auto)
8.9 dB(A) @ 1 m
Ambient Temperature
−4 °F to 113 °F (−20 °C to 45 °C)
Optical
Light Source
4 (RGBWwL) LED Engines
Lumens
4,285
Lumens (w/CYC Diffusion)
3,795
Lumens (w/Half Diffusion)
4,372
Lumens (w/Stealth Diffusion)
1,257
Illuminance
874 lux @ 5 m
Illuminance (w/CYC Diffusion)
276 lux @ 5 m
Illuminance (w/Half Diffusion)
595 lux @ 5 m
CRI
95
Color Temperature (Range)
2800 to 8000 K
Color Temperature (At Full)
9056 K
Beam Angle
16.5°
Beam Angle (w/CYC Diffusion)
27.3°
Beam Angle (w/Half Diffusion)
17.7°
Beam Angle (w/Stealth Diffusion)
25.3°
Field Angle
33.4°
Field Angle (w/CYC Diffusion)
74.3°
Field Angle (w/Half Diffusion)
43.7°
Field Angle (w/Stealth Diffusion)
59.7°
Selectable PWM
1,000 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 12,000 Hz, 25,000 Hz
Performance
Dimmer
Electronic
Shutter/Strobe
Electronic
Strobe Rate
0 to 30 Hz
Dim Modes
4
Dim Curves
4
Standalone Color Mixing
Yes
Color Temperature Presets
Yes
Built-In Automated Programs
Yes
Control
Control Protocol
Art-Net, sACN, DMX, CRMX, RDM
Modes/Personalities
32 personalities
DMX Channels (1 Cell)
CCT 4ch, HSV 4ch, RGB 3ch, RGBW 4ch, RGBWL 5ch, RGBWL-16bit 10ch, RGB Ext. 10ch, RGBW Ext. 11ch, RGBWL Ext. 12ch, RGBWL Full 19ch, XY 4ch, XY Ext. 9ch
DMX Channels (2 Cell)
CCT 7ch, HSV 7ch, RGB 6ch, RGBW 8ch, RGBWL 10ch, RGBWL-16bit 20ch, RGB Ext. 17ch, RGBW Ext. 19ch, RGBWL Ext. 21ch, RGBWL Full 35ch
DMX Channels (4 Cell)
CCT 13ch, HSV 13ch, RGB 12ch, RGBW 16ch, RGBWL 20ch, RGBWL-16bit 40ch, RGB Ext. 31ch, RGBW Ext. 35ch, RGBWL Ext. 39ch, RGBWL Full 67ch
Connectivity
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
Power Input
Seetronic Powerkon IP65
Power Output
Seetronic Powerkon IP65
Data Connectors
5-pin IP65 XLR, Seetronic etherCON compatible
Software Connection
USB
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current @ 100 V
110 W, 1.12 A @ 100 V, 60 Hz
Power and Current @ 120 V
108 W, 0.93 A @ 120 V, 60 Hz
Power and Current @ 208 V
106 W, 0.59 A @ 208 V, 60 Hz
Power and Current @ 230 V
105 W, 0.48 A @ 230 V, 50 Hz
Power and Current @ 240 V
107 W, 0.46 A @ 240 V, 60 Hz
Construction
Dimensions
12.13 x 6.30 x 8.36 in (308 x 160 x 212.4 mm)
Weight
13.1 lbs (6.1 kg)
Housing Material
Aluminum diecast, aluminum profile
Exterior Color
Black
Included Items
Fixture
COLORado Solo Bar 1
Power Cable
Seetronic Powerkon IP65
Mounting
Omega brackets with mounting hardware
Filters
50/50 Filter, CYC Filter, Stealth Filter, Clear Protective Filter (Installed)
Glare Shield
Included
