Chauvet Pro COLORado Solo Batten IP65 RGBAW Linear Wash Fixture

Chauvet Pro COLORado Solo Batten IP65 RGBAW Linear Wash Fixture

SoundPro Item: 34290 | Part Number: COLORADOSOLOBATTEN

$2,400.00
$2,755.00 $2,400.00
Your Price Sold out
MSRP: $2,755.00 | MAP: $2,400.00

Usually ships in 5-7 business days

  • Homogenized Optics Eliminate Visible Pixels For A True Single-Bar Appearance
  • Twelve Individually Addressable Sections Enable Full Pixel-Mapping Creativity
  • RGBAW LED Engine Delivers Rich Saturation Across Full-Spectrum Color Mixing
  • Adjustable Color Temperature Presets Support Seamless Matching To Ambient Sources
  • Multiple Smooth Dimming Curves Provide Broadcast-Safe, Flicker-Free Output
  • IP65 Housing With IP-Rated Connectors Enables Reliable Outdoor And All-Weather Use
  • Password-Protected Onboard Display Allows Secure Configuration In Shared Production Environments
Log in or register for YOUR best price

The COLORado Solo Batten is built for lighting designers and production teams who need a linear wash that eliminates the visible dot-grid look common to standard batten fixtures. Its proprietary homogenizing optics blend 144 RGBAW LEDs into one continuous, seamless bar of light, making it an ideal choice for stage cyc work, broadcast backdrops, and event upstage scenery where clean, even coverage is non-negotiable.

Where the fixture separates itself from comparable battens is in its dual identity: run it as a single unified source for wide color washes, or unlock individual control over its twelve square sections for pixel-mapping effects through Art-Net, sACN, DMX, or RDM. With 37 control personalities and color temperature presets spanning a wide range, it adapts equally well to theatrical programming consoles, broadcast control systems, and live event rigs without compromising output quality at the edges of the lens.

The aluminum die-cast housing carries a full IP65 rating with matching IP-rated Seetronic Powerkon power connections and etherCON data ports, so the fixture holds up on outdoor festival stages and in permanent installations subject to moisture and dust. Auto-ranging voltage input and power-linking capability reduce distribution complexity on large rigs, while selectable PWM frequencies and five dimming curves give camera operators and directors the flicker-free performance broadcast productions require.

Downloads

View full details

Specifications

Certifications
IP Rating
IP65, temporary outdoor/wet use
Certifications
CE, MET, FCC
Ambient Temperature Range
-4 °F to 113 °F (-20 °C to 45 °C)
Optical
Light Source
144 LEDs (24 red, 24 green, 24 blue, 24 amber, 48 white) 3 W, (612 mA) 50,000 hours life expectancy
Color Temperature Range
1800 to 8000 K
Installed Optics
18°
Beam Angle (Horizontal)
20°
Beam Angle (Vertical)
16°
Beam Angle (Horizontal w/filter)
37°
Beam Angle (Vertical w/filter)
15°
Field Angle (Horizontal)
34°
Field Angle (Vertical)
29°
Field Angle (Horizontal w/filter)
63°
Field Angle (Vertical w/filter)
30°
Lumens
6,968
Illuminance (Total)
3,870 lux @ 5 m
Illuminance (w/filter)
1,230 lux @ 5 m
Selectable PWM
600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
Dynamic Effects
Dimmer
Electronic
Shutter/Strobe
Electronic
Strobe Rate
0 to 25 Hz
Standalone Color Mixing
Yes
Color Temperature Presets
Yes
Dim Modes
5
Built-in Automated Programs
Yes
Customizable Programs
Yes
Recall Custom Programs
Yes
Control
Control Protocol
Art-Net, DMX, RDM, sACN
DMX Channels
1 Cell: 3, 4, 5, 8, 8, 9, 10, 13, 16 / 2 Cell: 6, 8, 10, 15, 15, 17, 19, 20, 30 / 3 Cell: 9, 12, 15, 21, 22, 24, 27, 30, 43 / 12 Cell: 36, 48, 60, 75, 85, 87, 99, 120, 160
Art-Net Channels
1 Cell: 3, 4, 5, 8, 8, 9, 10, 13, 16 / 2 Cell: 6, 8, 10, 15, 15, 17, 19, 20, 30 / 3 Cell: 9, 12, 15, 21, 22, 24, 27, 30, 43 / 12 Cell: 36, 48, 60, 75, 85, 87, 99, 120, 160
Modes/Personalities
37 personalities
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current @ 120 V
336 W, 3.046 A @ 120 V, 60 Hz
Power and Current @ 208 V
336 W, 1.610 A @ 208 V, 60 Hz
Power and Current @ 230 V
339 W, 1.602 A @ 230 V, 50 Hz
Power Linking
4 units @ 120 V; 8 units @ 208 V; 8 units @ 230 V
Connectivity
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
Power Input
Seetronic Powerkon IP65
Power Output
Seetronic Powerkon IP65
Data Connectors
5-pin IP65 XLR, Seetronic etherCON IP65
Cable Length (Power)
5 ft (1.5 m)
Construction
Dimensions
39.86 x 9.06 x 9.84 in (1012.5 x 230 x 249.8 mm)
Weight
41.9 lbs (19 kg)
Exterior Color
Black
Housing Material
Aluminum die-cast
Accessory Holder/Gel Frame Size
38.75 x 3.81 in (984.25 x 97 mm)
Included Items
Included
COLORado Solo Batten with glare shield, Seetronic Powerkon IP65 power cord, wall washing filter
