Specifications
Certifications
IP Rating
IP66, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
Regulatory Certifications
CE, MET, FCC
Temperature (Ambient)
4 °F to 113 °F (-20 °C to 45 °C)
Optical
Light Source
1 LED (CW) 588 W, 4.6 A, 7500 K, 50,000 hours life expectancy
Color Temperature (At Full)
7,242 K
CRI
71.4
CQS
70.8
TLCI
51
CRI With CRI Filter
90.3
CQS With CRI Filter
89.1
TLCI With CRI Filter
70
CTO Color Temperature At Full
3895 K
CTB Color Temperature
8587 K
Front Lens Diameter
127 mm
Beam Angle
6° to 42°
Field Angle
7.1° to 54.1°
Cutoff Angle
7.7° to 56.5°
Zoom Range
6° to 54.1°
Lumens – Source
43,500
Lumens – Output
25,840
Illuminance (6°)
70,007 lux @ 5 m
Illuminance (54.1°)
2,624 lux @ 5 m
Selectable PWM
600 Hz, 1,200 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
Dynamic Effects
Pan / Tilt
540° / 270°
Pan / Tilt Ranges
540°, 360°, 180° pan / 270°, 180°, 90° tilt
Color Wheel
7 colors (Red, Orange, Green, Magenta, Blue, CRI and CTB filters) + white, split colors, continuous scroll
CMY / CTO
CMY flags, CTO flag
Gobos (Wheel 1)
7 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
Gobos (Wheel 2)
9 + open (glass), continuous scroll at variable speeds
Gobo Size (Wheel 1)
25.5 mm outside, 18 mm image, 1.1 mm max thickness
Framing Shutters
4 blades, each with dual axis movement, full blackout
Framing Shutter Rotation
+/- 60°
Prism
5 facets, motorized, rotating
Strobe Rate
0 to 20 Hz
Dimmer
Electronic
Zoom
Motorized
Focus
Motorized
Frost
Motorized
Iris
Motorized
Move-In-Black
Yes
Dim Curves
4
Control
Control Protocol
Art-Net, DMX, RDM, W-DMX, sACN
DMX Channels
32 or 48
Art-Net Channels
32 or 48
Modes / Personalities
2 (32, 48)
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power / Current @ 100V 60Hz
800 W, 8.20 A
Power / Current @ 120V 60Hz
800 W, 6.82 A
Power / Current @ 208V 60Hz
779 W, 3.77 A
Power / Current @ 230V 50Hz
763 W, 3.41 A
Power / Current @ 240V 50Hz
767 W, 3.34 A
Breaker Size
F15 A, 250 V
Connectivity
Power Connection
Termination-ready bare-ended
Power Input
Proprietary IP65
Data Connection
Bare wired to proprietary IP65 input cable
Data Input / Output
Termination-ready bare-ended
Cable Length (Power Input)
5 ft (1.5 m)
Cable Length (Hardwire Connection)
6.6 ft (2 m)
Cable Length (Signal In/Out)
5 ft (1.5 m)
Cable Length (Signal Hardwire Connection)
6.6 ft (2 m)
Construction
Dimensions
9.92" x 15.28" x 27.52" (252 x 388 x 699 mm)
Weight
70.2 lbs (31.9 kg)
Exterior Color
C5M rated (White)
Housing Material
Aluminum diecast, high-impact flame-retardant polymer, steel
Included Items
Includes
Maverick Storm 2 Profile M fixture, omega bracket with mounting hardware (2 Allen Key bolts), display cover, IP5Power extension cable, DMX adapter
