Specifications
Certifications
IP Rating
IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
Certifications
CE, MET, FCC, CB, UKCA
Optical
Light Source
1 LED (CW) 1250 W, 4 A, 7500 K, 50,000 hours life expectancy
Lumens – Source
94,000
Lumens – Output
60,756
Color Temperature (At Full)
6895 K
CTO Color Temperature (At Full)
2978 K
CTB Color Temperature
8639 K
CRI
71.5
CQS
71.4
TLCi
71.5
CRI With CRI Filter
91
CQS With CRI Filter
88.8
TLCi With CRI Filter
73
Front Lens Diameter
188 mm
Beam Angle
6.2° to 48.7°
Field Angle
8.4° to 54.1°
Cutoff Angle
8.8° to 58.3°
Zoom Range
6.4° to 58.3°
Illuminance (6.2°)
127,159 lux @ 5 m
Illuminance (58.3°)
4,019 lux @ 5 m
Selectable PWM
600 Hz, 1,200 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
Dynamic Effects
Pan Range
540° (selectable: 540°, 360°, 180°)
Tilt Range
270° (selectable: 270°, 180°, 90°)
Color Wheel
6 colors (Red, Yellow, Green, UV, CRI filter, CTB filter) + white, split colors, continuous scroll
CMY / CTO
CMY flags, CTO flag
Gobos (Wheel 1)
6 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
Gobos (Wheel 2)
6 + open (glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
Gobo Wheel 1 Size
30 mm outside, 25 mm image, 1.1 mm max thickness
Gobo Wheel 2 Size
30 mm outside, 25 mm image, 1.1 mm max thickness
Framing Shutters
4 blades, each with dual axis movement, full blackout
Framing Shutter Rotation
±60°
Prism 1
5 linear facets, motorized, rotating
Prism 2
5 circular facets, motorized, rotating
Dimmer
Electronic, 16-bit
Shutter / Strobe
Electronic
Strobe Rate
0 to 20 Hz
Zoom
Motorized
Focus
Motorized
Frost
Motorized (light and medium)
Iris
Motorized
Animation
Motorized
Dim Curves
4
Move-In-Black
Yes
Built-In Sky Tracker Mode
Yes
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power / Current @ 120 V
1780 W, 15.07 A @ 120 V, 60 Hz
Power / Current @ 208 V
1740 W, 8.70 A @ 208 V, 60 Hz
Power / Current @ 230 V
1760 W, 7.79 A @ 230 V, 50 Hz
Breaker Size
25 A, 750 V
Control
Control Protocol
Art-Net, DMX, RDM, W-DMX, sACN
DMX Channels
38 or 55
Art-Net Channels
38 or 55
Modes / Personalities
2 (38ch, 55ch)
Connectivity
Power Connection
Seetronic Powerkon IP65
Power Input / Output
Seetronic Powerkon IP65
Data Connectors
5-pin IP rated XLR, Neutrik IP rated RJ45 in/out
Power Cable Length
5' (1.5 m)
Construction
Dimensions
18.3" x 11.93" x 32.91" (465 x 303 x 836 mm)
Weight
111.4 lbs (50.6 kg)
Exterior Color
Black
Housing Material
Aluminum diecast, high-impact flame-retardant polymer, steel
Environmental
Noise Level (Idle)
38.5 dB(A) @ 1 m
Noise Level (Max)
50.5 dB(A) @ 1 m
Noise Level (Auto)
43.3 dB(A) @ 1 m
Temperature (Ambient)
4 °F to 113 °F (-20 °C to 45 °C)
Included Items
Included
Maverick Storm 4 Profile, Seetronic Powerkon IP65 power cord to bare end, (2) 140-D Omega bracket with mounting hardware
