Chauvet Pro onAir Panel Min IP Compact Full-Spectrum LED Soft Light

Chauvet Pro onAir Panel Min IP Compact Full-Spectrum LED Soft Light

SoundPro Item: 130117 | Part Number: ONAIRPANELMINIP

$1,209.00
$1,388.00 $1,209.00
Your Price Sold out
MSRP: $1,388.00 | MAP: $1,209.00

Usually ships in 5-7 business days

  • IP65 Full-Weather Certification With Pressure-Equalizing GORE Valve For Outdoor Reliability
  • Virtual Color Wheel Provides Instant Access To Popular Gel Colors Without Physical Filters
  • Fanless Cooling Delivers Completely Silent Operation For Sound-Sensitive Production Environments
  • Adjustable PWM Eliminates Flicker For Any Camera Frame Rate Or Shutter Speed
  • CRMX And RDM Support Enable Wireless DMX Control And Remote Configuration
  • Removable PSU With 28 VDC XLR Input Enables Battery-Powered On-Location Operation
  • Drop-In Accessory Slot And Ball Head Mount Allow Tool-Free Rigging Reconfiguration
  • USB Port Enables Direct Firmware Updates Without External Programmer
Log in or register for YOUR best price

The Chauvet Pro onAir Panel Min IP is built for cinematographers, broadcast engineers, and production crews who need a compact, weatherproof soft light that performs at a professional level in any environment. Its IP65-rated aluminum alloy housing handles rain, dust, and demanding on-location conditions without compromise, making it equally at home on an outdoor film set, a mobile broadcast unit, or a low-ceiling studio install where trim height matters.

Where comparable panels force a choice between color quality and portability, the onAir Panel Min IP delivers CRI 95 and a full 2800 K to 8000 K color temperature range with plus/minus green adjustment, emulated redshift, and a virtual color wheel — giving colorists and DPs the precision needed to match practical sources or push creative looks without physical gels. The removable power supply and 28 VDC 3-pin XLR input mean the fixture can run entirely off an external battery pack, a critical advantage for run-and-gun ENG, documentary, and remote production work.

For camera-facing deployments, adjustable PWM up to 25,000 Hz eliminates flicker at any frame rate, and the fanless cooling system ensures zero noise interference on set. DMX, RDM, and CRMX wireless control protocols provide the integration depth required for both operator-driven live productions and complex installed environments. The ball head mount with Baby Pin and clamp adapters, combined with a built-in drop-in accessory slot, gives riggers fast, tool-free reconfiguration between setups.

Downloads

View full details

Specifications

Certifications
IP Rating
IP65, temporary outdoor use, with pressure equalizing M12 GORE valve
Certifications
CE, MET, FCC
Ambient Temperature
−4 °F to 113 °F (−20 °C to 45 °C)
Optical
Light Source (RGB)
40 LEDs (tri-color RGB), 1.4 W, 150 mA, 50,000 hr life expectancy
Light Source (WW)
40 LEDs (WW), 0.50 W, 150 mA, 50,000 hr life expectancy
Color Temperature Range
2800 to 8000 K
Color Temperature At Max
6367 K
CRI
95
Beam Angle
94.9°
Field Angle
149.4°
Lumens
2,573
Illuminance
47 lux @ 5 m
Selectable PWM
600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
Performance
Dimmer
Electronic
Shutter/Strobe
Electronic
Strobe Rate
0 to 27 Hz
Independent Color Mixing
Yes
Color Temperature Presets
Yes
Dimming Modes
4
Dim Curves
4
Built-In Automated Programs
Yes
Control
Control Protocol
CRMX, RDM
DMX Channels
1, 3, 4, 5, 6, 8, 10, 11, 15
Modes/Personalities
9 personalities (1, 3, 4, 5, 6, 8, 10, 11, 15Ch)
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power And Current @ 120 V
49 W, 0.419 A @ 120 V, 60 Hz
Power And Current @ 208 V
52 W, 0.260 A @ 208 V, 60 Hz
Power And Current @ 230 V
57 W, 0.246 A @ 230 V, 50 Hz
Connectivity
Power Connection
Edison plug (local) to Seetronic Powerkon IP65
Power Input (AC)
Seetronic Powerkon IP65
Power Input (DC)
28 VDC, 3-pin IP65 XLR
Power Cable Length
5 ft (1.5 m)
Software Connection
USB
Dimensions
Dimensions With PSU
10 x 5.62 x 4.29 in (254 x 143 x 109 mm)
Dimensions Without PSU
10 x 4.13 x 4.29 in (254 x 105 x 109 mm)
Weight
Weight With PSU
6.2 lbs (2.9 kg)
Weight Without PSU
4.2 lbs (2.0 kg)
Construction
Housing Material
Aluminum Alloy
Exterior Color
Black
Included Items
onAir Panel Min IP Fixture
Included
Seetronic Powerkon IP65 Cable
Included
Mounting Hardware
Included
