Chauvet Pro Ovation CYC 3 FC RGBAL Cyclorama Wash and Footlight

Chauvet Pro Ovation CYC 3 FC RGBAL Cyclorama Wash and Footlight

SoundPro Item: 137108 | Part Number: OVATIONCYC3FC

$2,055.50
$2,360.00 $2,055.50
Your Price Sold out
MSRP: $2,360.00 | MAP: $2,055.50

Usually ships in 5-7 business days

  • RGBAL Color System With CRI 90 Renders Accurate Skin Tones and Costume Colors on Camera
  • Adjustable PWM Up To 25,000 Hz Eliminates Rolling Shutter Flicker For Broadcast and Film
  • Theatre-Ready 16-Bit Dimming Delivers Exceptionally Smooth Fades on Master and Individual Colors
  • Fanless Convection Cooling Ensures Completely Silent Operation In Studio and Stage Environments
  • Integrated Kick Stand and Adjustable Glare Shield Enable Precise Beam Shaping Without Extra Hardware
  • Virtual Color Wheel Provides Instant Access To Gel Matches and Color Temperature Presets
  • RDM Support Enables Remote Addressing and Configuration Across Complex Multi-Fixture Rigs
Log in or register for YOUR best price

The Ovation CYC 3 FC is built for lighting directors and integrators who need a wide, even wash across cycloramas, backdrops, or stage floors without introducing noise or on-camera artifacts. Its fully convection-cooled aluminum die-cast housing makes it the go-to choice for theatre, broadcast studios, and virtual production stages where fan noise is unacceptable and camera flicker is a deal-breaker. The one-meter form factor integrates cleanly into flown or floor-mounted positions, and the included omega brackets plus integrated kick stand give riggers and programmers immediate flexibility at hang.

Where many cyc fixtures compromise on color accuracy, the RGBAL system here targets near-full-spectrum output across a 2800K to 6500K range with a CRI of 90 at 3200K — meaningful for broadcast and film applications where skin tones and costume colors must reproduce accurately on camera. The virtual color wheel provides instant access to popular gel matches and white-light presets, reducing programming time in fast-turnaround production environments. Adjustable PWM frequencies up to 25,000 Hz eliminate rolling shutter artifacts across a wide range of camera frame rates.

For touring and install teams building larger cyc systems, the Ovation CYC 3 FC power-links up to seven units at 230V and supports RDM for remote addressing across complex rigs. Its eleven DMX personalities scale from simple single-channel control to full 33-channel precision, accommodating everything from a basic theatrical plot to a detailed broadcast lighting console workflow. The fixture pairs directly with the Ovation CYC 1 FC for seamless coverage extension across wider cyclorama runs.

Downloads

View full details

Specifications

Certifications
Certifications
CE, MET, FCC, UKCA
IP Rating
IP20, dry location
Temperature (Ambient)
-4 °F to 113 °F (-20 °C to 45 °C)
Optical
Light Source
180 LEDs (36 red, 36 green, 36 blue, 36 amber, 36 lime) 2.5 W to 3.5 W (725 mA)
Color Temperature Range
2800 to 6500 K
CRI (3200K)
90
Beam Angle (Horizontal)
111.4°
Field Angle (Horizontal)
151.8°
Beam Angle (Vertical)
76.7°
Field Angle (Vertical)
134.4°
Lumens
19,575
Illuminance (Total)
280 lux @ 5 m
PWM Frequency
600, 1200, 2000, 4000, 6000, 25,000 Hz
Performance
Dimmer
Electronic
Shutter/Strobe
Electronic
Strobe Rate
0 to 29 Hz
Standalone Color Mixing
Yes
Color Temperature Presets
Yes
Dim Modes
4
Dim Curves
4
Built-In Automated Programs
Yes
Customizable Programs
No
Recall Custom Programs
No
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current (120 V)
345 W, 2.93 A @ 120 V, 60 Hz
Power and Current (208 V)
338 W, 1.77 A @ 208 V, 60 Hz
Power and Current (230 V)
334 W, 1.64 A @ 230 V, 50 Hz
Power Linking
4 units @ 120 V; 6 units @ 208 V; 7 units @ 230 V
Connectivity
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
Power Input
Seetronic Powerkon IP65
Power Output
Seetronic Powerkon IP65
Data Connectors
5-pin XLR
Cable Length (Power)
5 ft (1.5 m)
Control Protocol
DMX, RDM
DMX Channels
1, 3, 5, 7, 10, 12, 13, 16, 17, 33
Modes/Personalities
11 personalities (1, 3, 5, 7, 10, 12, 13, 16, 17, 33, HSV)
Construction
Dimensions
47.13 x 6.30 x 4.33 in (1197 x 160 x 110 mm)
Weight
24.6 lbs (11.2 kg)
Exterior Color
Black
Housing Material
Aluminum die-cast
Included Items
Fixture
OVATION CYC-3 FC
Power Cord
Seetronic Powerkon power cord
Mounting Hardware
Omega brackets with mounting hardware
