Chauvet Pro Ovation E-260 Ellipsoidal Silent LED ERS Fixture | White

SoundPro Item: 201144 | Part Number: OVATIONE260WWWHT-2

$1,350.00

~~$1,550.00~~ $1,350.00

Your Price Sold out

MSRP: $1,550.00 | MAP: $1,350.00

Usually ships in 5-7 business days

Output Surpasses 750W Tungsten From A Single 230W LED Source
CRI 96 Rendering Maintains Color Accuracy For Broadcast And Live Performance
Flat Even Field Of Light Produces Crisp, High-Quality Gobo Projections
16-Bit Dimming With Four Selectable Curves For Smooth Theatrical Fades
Adjustable PWM At Six Selectable Frequencies Eliminates Camera Flicker
DMX And RDM Support Enable Remote Configuration And Flexible Control
Compatible With Industry-Standard Lens Tubes And Common ERS Accessories

Log in or register for YOUR best price

Quantity

The Chauvet Pro Ovation E-260 Ellipsoidal is built for lighting directors, integrators, and production designers who need a professional-grade LED ERS fixture capable of replacing high-wattage tungsten units without compromise. A single 230W LED source delivers output that surpasses a traditional 750W tungsten spotlight, while CRI 96 rendering keeps skin tones and set colors accurate under camera or to the human eye. The flat, even field of light makes it a reliable choice for gobo projection in theatrical productions, and the virtually silent convection-cooled design satisfies the strict noise floors required in broadcast studios, houses of worship, and live recording environments.

Control flexibility is central to the E-260 platform. Sixteen-bit dimming with four selectable curves gives programmers precise fade control down to the lowest levels, and adjustable PWM with six selectable frequencies eliminates flicker on camera sensors across a wide range of frame rates. DMX and RDM support allow remote configuration from the console or a handheld device, reducing time spent on a ladder. Four DMX personalities provide compatibility with simple one-channel plots and complex six-channel rigs. The fixture accepts industry-standard lens tubes across a wide range of angles, as well as zoom lenses, gobo holders, and color accessories common to any ERS-based rig, protecting existing inventory investments. Available in black or white housing finishes to suit architectural installs and traditional stage environments alike.

Downloads

View full details

Specifications

Certifications

CE, MET, FCC, UKCA

IP Rating

IP20, dry location

Light Source

1 LED (WW) 230 W, 3.6 A, 3149 K, 50,000 hours life expectancy

Color Temperature (at full)

3149 K

CRI

96

Lumens (w/19° lens)

7,587

Lumens (w/26° lens)

10,284

Lumens (w/36° lens)

10,121

Lumens (w/50° lens)

9,655

Performance

Strobe Rate

0 to 27 Hz

Selectable PWM

600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

Dimming Modes

4

Dim Modes

4

Zoom

Manual

Dimmer

Electronic

Shutter/Strobe

Electronic

Built-in Automated Programs

Yes

Color Temperature Presets

No

Beam Angle

Beam Angle (w/5° lens)

6°

Beam Angle (w/10° lens)

8°

Beam Angle (w/14° lens)

11°

Beam Angle (w/19° lens)

13°

Beam Angle (w/26° lens)

16°

Beam Angle (w/36° lens)

20°

Beam Angle (w/50° lens)

28°

Beam Angle (w/15°-30° lens)(Narrow)

12°

Beam Angle (w/15°-30° lens)(Wide)

14°

Beam Angle (w/25°-50° lens)(Narrow)

21°

Beam Angle (w/25°-50° lens)(Wide)

22°

Field Angle

Field Angle (w/5° lens)

7°

Field Angle (w/10° lens)

10°

Field Angle (w/14° lens)

14°

Field Angle (w/19° lens)

18°

Field Angle (w/26° lens)

25°

Field Angle (w/36° lens)

34°

Field Angle (w/50° lens)

50°

Field Angle (w/15°-30° lens)(Narrow)

15°

Field Angle (w/15°-30° lens)(Wide)

29°

Field Angle (w/25°-50° lens)(Narrow)

26°

Field Angle (w/25°-50° lens)(Wide)

46°

Illuminance

Illuminance (w/5° lens)

41,400 lux @ 5 m

Illuminance (w/10° lens)

23,300 lux @ 5 m

Illuminance (w/14° lens)

13,439 lux @ 5 m

Illuminance (w/19° lens)

9,256 lux @ 5 m

Illuminance (w/26° lens)

6,910 lux @ 5 m

Illuminance (w/36° lens)

4,053 lux @ 5 m

Illuminance (w/50° lens)

1,703 lux @ 5 m

Illuminance (w/15°-30° lens)(Narrow)

16,827 lux @ 5 m

Illuminance (w/15°-30° lens)(Wide)

10,626 lux @ 5 m

Illuminance (w/25°-50° lens)(Narrow)

7,210 lux @ 5 m

Illuminance (w/25°-50° lens)(Wide)

3,295 lux @ 5 m

Connectivity

Data Connectors

3- and 5-pin XLR

Control Protocol

DMX, RDM

DMX Channels

1, 2, 3 or 6

Modes/Personalities

4 personalities (1, 2, 3, 6)

Power Connection

Edison (local) plug to Seetronic Powerkon IP65

Power Input

Seetronic Powerkon IP65

Power Output

Seetronic Powerkon IP65

Cable Length (power)

5 ft (1.5 m)

Electrical

Input Voltage

100 to 240 VAC, 50/60 Hz (auto-ranging)

Power Linking

6 units @ 120 V; 10 units @ 208 V; 12 units @ 230 V

Power and Current (100 V, 60 Hz)

225 W, 2.36 A

Power and Current (120 V, 60 Hz)

223 W, 1.84 A

Power and Current (208 V, 60 Hz)

230 W, 1.10 A

Power and Current (230 V, 50 Hz)

231 W, 1.00 A

Power and Current (240 V, 60 Hz)

232 W, 1.02 A

Construction

Exterior Color

White

Gobo Size (Optional) A

100 mm outside, 75 mm image, 2.5 mm max. thickness

Gobo Size (Optional) B

86 mm outside, 64.5 mm image, 2.5 mm max. thickness

Dimensions

Dimensions (fixture only)

19.49 x 11.22 x 19.17 in (495 x 285 x 487 mm)

Dimensions (w/5° lens extended)

42.79 x 14.17 x 14.48 in (1087 x 360 x 368 mm)

Dimensions (w/10° lens extended)

34.09 x 12.16 x 12.48 in (866 x 309 x 317 mm)

Dimensions (w/14° lens extended)

28.74 x 11.22 x 19.17 in (730 x 285 x 487 mm)

Dimensions (w/26° lens extended)

25.91 x 11.22 x 19.17 in (658 x 285 x 487 mm)

Dimensions (w/15°-30° lens)

32.87 x 14.61 x 14.61 in (835 x 371 x 371 mm)

Dimensions (w/25°-50° lens)

27.17 x 14.61 x 14.61 in (690 x 371 x 371 mm)

Weight

Weight (fixture only)

15.4 lbs (7 kg)

Weight (w/5° lens)

21.2 lbs (9.7 kg)

Weight (w/10° lens)

19.2 lbs (8.8 kg)

Weight (w/14° lens)

20.8 lbs (9.43 kg)

Weight (w/26° lens)

19.4 lbs (8.80 kg)

Weight (w/15°-30° lens)

29.4 lbs (13.34 kg)

Weight (w/25°-50° lens)

27 lbs (12.25 kg)

Accessory Holder/Gel Frame Size

Accessory Holder/Gel Frame Size (5° lens)

14 in (356 mm)

Accessory Holder/Gel Frame Size (10° lens)

12 in (304 mm)

Accessory Holder/Gel Frame Size (14° lens)

7.5 in (191 mm)

Accessory Holder/Gel Frame Size (19°, 26°, 36°, and 50° lens)

6.25 in (159 mm)

Accessory Holder/Gel Frame Size (15°-30° lens)

7.5 in (191 mm)

Accessory Holder/Gel Frame Size (25°-50° lens)

7.5 in (191 mm)

Included Items

What's Included

Ovation E-260WW, Seetronic Powerkon IP65 power cord

Required Accessories

Lens Tube: 19°, 26°, 36°, 50°

Compatible Accessories

CTC-50HC, CTC-50HCN, TRUE 1 Style Power Extension Cables, 3-pin or 5-pin DMX Cables, Color Blending Filters: DF60X1D, DF20D, RDM2go, Ovation Zoom Lenses: OHDZOOM1530, OHDZOOM2550, Gobo Holder: Standard S4 size Sandwich Style or Iris Slot Style gobo holder for A or B size gobos

Identifiers

Model

OVATIONE260WWWHT-2
