Chauvet Pro Ovation E-2 FC Compact RGBA-Lime LED Ellipsoidal Spotlight

Chauvet Pro Ovation E-2 FC Compact RGBA-Lime LED Ellipsoidal Spotlight

SoundPro Item: 137109 | Part Number: OVATIONE2FC

$1,412.50
$1,622.00 $1,412.50
Your Price Sold out
MSRP: $1,622.00 | MAP: $1,412.50

Usually ships in 5-7 business days

  • Full-Spectrum RGBA-Lime Engine Achieves CRI 93 Output Across A Wide Color Gamut
  • One-Touch Focus Mode Enables Solo Adjustments Without A Console Operator
  • Standalone Color Mixing Allows Programming And Operation Without A DMX Controller
  • Plus/Minus Green Adjustment And Emulated Red-Shift For Camera-Ready Color Matching
  • Integrated Framing Shutters Provide Precise Beam Shaping And Gobo Projection Support
  • Selectable PWM Frequencies Eliminate Flicker Artifacts In Broadcast And Film Capture
  • USB Firmware Update Port Simplifies Software Maintenance Without Additional Tools
Log in or register for YOUR best price

The Chauvet Pro Ovation E-2 FC is purpose-built for lighting directors and production designers who need broadcast-quality color rendering in compact venue and studio installations. Its six-color RGBA-Lime LED engine — spanning 72 LEDs across red, green, blue, cyan, amber, and lime channels — achieves a CRI of 93 at 3200 K and covers a color temperature range from 2800 K to 8000 K, making it a dependable tool for skin tones on camera, architectural washes, and theatrical specials alike. The aluminum die-cast housing keeps operating weight manageable for overhead rigging while delivering the thermal stability needed for long burn times without fan noise that would compromise broadcast or intimate live performance environments.

For integrators and rental houses specifying ERS-style fixtures, the Ovation E-2 FC competes directly with larger, heavier units by pairing a manual 23.8° to 51.8° zoom range with framing shutters, a 6.25

Downloads

View full details

Specifications

Certifications
Certifications
CE, MET, FCC, UKCA
IP Rating
IP20, dry location
Temperature (Ambient)
-4 °F to 113 °F (-20 °C to 45 °C)
Optical
Light Source
72 LEDs (15 red, 11 green, 6 blue, 4 cyan, 14 amber, 22 lime) 6 to 9.75 W, (1.5 A) 50,000 hours life expectancy
Color Temperature (Range)
2800 to 8000 K
Color Temperature (At Full)
4525 K
CRI (3200 K)
93
Zoom Range
23.8° to 51.8°
Beam Angle (Spot)
23.8°
Beam Angle (Flood)
46.4°
Beam Angle (50% Zoom)
38.7°
Field Angle (Spot)
25.6°
Field Angle (Flood)
51°
Field Angle (50% Zoom)
41.3°
Cutoff Angle (Spot)
24.9°
Cutoff Angle (Flood)
51.8°
Cutoff Angle (50% Zoom)
41.9°
Lumens (Spot)
3708 lm
Lumens (Flood)
5608 lm
Lumens (50% Zoom)
5147 lm
Illuminance (Spot)
1107 lux @ 5 m
Illuminance (Flood)
488 lux @ 5 m
Illuminance (50% Zoom)
595 lux @ 5 m
Selectable PWM
600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
Performance
Framing Shutters
Yes
Dimmer
Electronic
Shutter/Strobe
Electronic
Zoom
Manual
Focus
Manual
Strobe Rate
0 to 25 Hz
Standalone Color Mixing
Yes
Color Temperature Presets
Yes
Dim Modes
4
Dim Curves
4
Built-In Automated Programs
Yes
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current (120 V)
208 W, 1.71 A @ 120 V, 60 Hz
Power and Current (208 V)
219 W, 1.10 A @ 208 V, 60 Hz
Power and Current (230 V)
220 W, 0.98 A @ 230 V, 50 Hz
Power Linking
7 units @ 120 V; 10 units @ 208 V; 12 units @ 230 V
Controls
Control Protocol
DMX, RDM
DMX Channels
1, 4, 5, 7, 11, 13ch1, 13ch2, 17 or HSV
Modes/Personalities
9 personalities (1, 4, 5, 7, 11, 13ch1, 13ch2, 17 or HSV)
Connectivity
Power Connection
Edison (Local) plug to Seetronic Powercon IP65
Power Input
Seetronic Powercon IP65
Power Output
Seetronic Powercon IP65
Data Connectors
5-pin XLR
Cable Length (Power)
5 ft (1.5 m)
Software Connection
USB
Dimensions
Dimensions
18.1 x 12.2 x 17.5 in (461 x 310 x 445 mm)
Accessory Holder/Gel Frame Size
6.25 in (159 mm)
Gobo Size (Optional)
"M": 66 mm (outside), 48 mm (image), 2 mm (max. thickness)
Weight
Weight
14.8 lb (6.7 kg)
Construction
Exterior Color
Black
Housing Material
Aluminum die-cast
Included Items
Included
Ovation E-2FC, Seetronic Powerkon power cord, Ovation Metal Gobo Holder ("M" Size), Soft Focus Filter, Quick Reference Guide or User Manual
