Chauvet Pro Ovation Rêve F-3 IP RGBAM Motorized Fresnel With IP65 Rating

Chauvet Pro Ovation Rêve F-3 IP RGBAM Motorized Fresnel With IP65 Rating

SoundPro Item: 143531 | Part Number: OVATIONREVEF3IP

$3,260.00
$3,742.00 $3,260.00
Your Price Sold out
MSRP: $3,742.00 | MAP: $3,260.00

Usually ships in 5-7 business days

  • Full-Spectrum RGBAM Engine Achieves CRI 96 For Accurate, Broadcast-Ready Color Reproduction
  • IP65 Weatherproof Housing Enables Dependable Deployment In Indoor And Outdoor Environments
  • Motorized Zoom Spans Wide To Tight Beams Without Repositioning The Fixture
  • Selectable PWM Frequencies Up To 25,000 Hz Eliminate On-Camera Flicker At Any Frame Rate
  • Virtual Color Wheel Provides Presets Matched To Popular Professional Gel Colors
  • Adjustable Yoke Design Supports Flexible Mounting In Low-Clearance Or Tight Rigging Situations
  • RDM Support With USB Firmware Port Simplifies Remote Configuration And Field Updates
Log in or register for YOUR best price

The Chauvet Pro Ovation Rêve F-3 IP is built for lighting professionals who need broadcast-grade color accuracy, weatherproof durability, and whisper-quiet operation in a single fixture. Designed for theaters, houses of worship, television and film sets, and the rental market, it performs reliably whether flown over a stage, mounted in a low-clearance venue, or deployed outdoors through a full production run. The IP65-rated aluminum alloy housing eliminates the need for additional weather protection on exterior installations, reducing rig complexity on touring and event builds.

The RGBAM light engine with 126 LEDs produces a CRI of 96 and a tunable color temperature range spanning 2800 K to 8000 K, giving cinematographers and LD's the flexibility to match tungsten, daylight, or any custom look without swapping gels. A virtual color wheel with presets matched to popular professional gel colors, combined with plus/minus green adjustment and emulated red-shift, delivers the color correction tools demanded by broadcast and film workflows directly from DMX or the three on-board control dials.

Motorized zoom from 10.6° to 68.2° covers everything from tight specials to wide soft washes without repositioning the fixture, while selectable PWM frequencies up to 25,000 Hz guarantee flicker-free performance at any frame rate or shutter angle. RDM support, a dedicated USB firmware port, and eight DMX personalities make the F-3 IP straightforward to integrate into any control infrastructure from small theatrical rigs to large-scale production networks.

Downloads

View full details

Specifications

Certifications
IP Rating
IP65, dry location
Certifications
CE, MET, FCC
Noise Level (Idle)
34.5 dB(A) @ 1 m
Noise Level (Auto)
37.2 dB(A) @ 1 m
Noise Level (On)
38.7 dB(A) @ 1 m
Ambient Temperature Range
-4 °F to 113 °F (-20 °C to 45 °C)
Optical
Light Source
126 LEDs (22 red, 14 green, 16 blue, 6 royal blue, 28 amber, 40 mint) 5.8 to 7.5 W, (1.95 A) 50,000 hours life expectancy
CRI
96
Color Temperature Range
2800 to 8000 K
Color Temperature (At Full)
5864 K
Beam Angle
10.6° to 68.2°
Field Angle
18.3° to 90.4°
Cutoff Angle
25.3° to 99.5°
Zoom Range
10.6° to 99.5°
Lumens (Narrow)
5232 lm
Lumens (Wide)
13374 lm
Illuminance (Narrow)
4869 lux @ 5 m
Illuminance (Wide)
482 lux @ 5 m
Illuminance (50%)
1587 lux @ 5 m
Front Lens Diameter
210.8 mm
Selectable PWM
750 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
Performance
Dimmer
Electronic
Shutter/Strobe
Electronic
Zoom
Motorized
Strobe Rate
0 to 30 Hz
Standalone Color Mixing
Yes
Color Temperature Presets
Yes
Dim Modes
4
Dim Curves
4
Built-In Automated Programs
Yes
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power And Current @ 120 V
532 W, 4.46 A @ 120 V, 60 Hz
Power And Current @ 208 V
519 W, 2.56 A @ 208 V, 60 Hz
Power And Current @ 230 V
526 W, 2.24 A @ 230 V, 50 Hz
Power Linking
2 units @ 120 V; 4 units @ 208 V; 5 units @ 230 V
Connectivity
Control Protocol
DMX, RDM
DMX Channels
1, 5, 6, 8, 12, 14ch1, 14ch2, 18 or HSV
Modes/Personalities
8 personalities (1, 5, 6, 8, 12, 14ch1, 14ch2, 18 or HSV)
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
Construction
Dimensions
16.02 x 13.47 x 20 in (406.9 x 342 x 508 mm)
Weight (Standard Yoke)
30.4 lb (13.8 kg)
Weight (Pole Yoke)
34.0 lb (15.5 kg)
Exterior Color
Black
Housing Material
Aluminum alloy
Accessory Holder/Gel Frame Size
7.5 in (191 mm)
Included Items
Included
Ovation Reve F-3 IP, Seetronic Powerkon power cord, gel frame, (1) 140mm Omega bracket with mounting hardware
