Chauvet Pro ROGUER1ESPOT 200W LED Moving Yoke Spot Fixture

Chauvet Pro ROGUER1ESPOT 200W LED Moving Yoke Spot Fixture

SoundPro Item: 143344 | Part Number: ROGUER1ESPOT

$2,207.00
$2,534.00 $2,207.00
Your Price Sold out
MSRP: $2,534.00 | MAP: $2,207.00

Usually ships in 5-7 business days

  • Dual Gobo Wheels Enable Gobo Morphing Transitions Between Patterns
  • Selectable LED Output Matches Legacy Rogue R1X Spot Brightness In Mixed Rigs
  • RDM Support Enables Remote Addressing And Diagnostics Without Physical Access
  • Selectable PWM Frequencies Eliminate Flicker For Video And Broadcast Applications
  • 16-Bit Master Dimmer Delivers Artifact-Free Fades Under Camera Scrutiny
  • True1-Compatible Power Linking Simplifies Cable Management For Multi-Fixture Runs
  • Two DMX Personalities Provide Flexibility Between Control Depth And Universe Efficiency
Log in or register for YOUR best price

The Rogue R1E Spot is built for lighting designers, mobile entertainers, and production teams outfitting small to medium venues who need a full-featured spot fixture without the footprint of a larger unit. Its 200W LED engine delivers output competitive with fixtures in higher wattage classes, while the 15.3° beam angle ensures tight, readable gobo projections even in wide rooms. The combination of a rotating interchangeable gobo wheel and a static scrolling wheel opens up gobo morphing that most single-wheel fixtures simply cannot achieve, giving programmers more creative options per channel count.

For integrators expanding an existing Rogue rig, the selectable LED max output mode allows the R1E Spot to match brightness levels of legacy Rogue R1X Spots — a practical advantage that eliminates visible intensity mismatches across a multi-fixture system. The 3-facet rotating prism, motorized iris, and frost filter give operators full beam-shaping control from a single head, reducing the need for additional fixtures in the rig. RDM support simplifies remote addressing and diagnostics across large installations, while True1-compatible power linking keeps cable management clean on congested stages.

Selectable PWM frequencies up to 15,000 Hz make the R1E Spot a reliable choice for broadcast and video production environments where flicker artifacts are a critical concern. The 16-bit master dimmer delivers smooth, artifact-free fades that hold up under camera scrutiny. With two DMX personalities — 16 or 19 channels — programmers can choose the right balance of control depth versus universe efficiency for any show file.

Downloads

View full details

Specifications

Certifications
Certifications
CE, MET, FCC, UKCA
IP Rating
IP20, dry location
Optical
Light Source
1 LED (CW) 200 W, 3.2 A, 7423 K, 50,000 hours life expectancy
Color Temperature (At Full)
7423 K
CRI
68
Beam Angle
15.3°
Field Angle
18.7°
Cutoff Angle
20.3°
Front Lens Diameter
90 mm
Lumens – Source
17,900
Lumens – Output
12,210
Illuminance (Total)
9,021 lux @ 5 m
Selectable PWM
600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz
Dynamic Effects
Pan And Tilt
540°/270°
Pan And Tilt Ranges
540°, 360°, 270° pan / 270°, 180°, 90° tilt
Colors
8 + white, split colors, continuous scroll at variable speeds
Gobos (1)
7 + open (7 metal), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds
Gobos (2)
8 + open (8 metal), continuous scroll at variable speeds
Gobo Size
Gobo Wheel 1 (rotating): 20 mm outside, 16 mm image, 1.5 mm max thickness
Dimmer
Electronic, 16-bit
Shutter/Strobe
Electronic
Strobe Rate
0 to 22 Hz
Focus
Motorized
Iris
Motorized
Prism
3-facet, motorized, rotating
Move In Black
Yes
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power And Current @ 120 V
315 W, 2.63 A @ 120 V, 60 Hz
Power And Current @ 208 V
306 W, 1.50 A @ 208 V, 60 Hz
Power And Current @ 230 V
303 W, 1.36 A @ 230 V, 50 Hz
Power Linking
4 units @ 120 V; 8 units @ 208 V; 8 units @ 230 V
Connectivity
Power Connection
Edison (local) plug to Seetronic PowerKon
Power Input
Seetronic PowerKon
Power Output
Seetronic PowerKon
Data Connectors
3-pin and 5-pin XLR
Cable Length (Power)
5 ft (1.5 m)
Software Update
USB-C
Control
Control Protocol
DMX, RDM
DMX Channels
16 or 19
Modes/Personalities
2 (16-channel, 19-channel)
Construction
Dimensions (Single Unit)
14.01 x 9.44 x 20.47 in (356 x 240 x 520 mm)
Weight (Single Unit)
31.2 lbs (14.2 kg)
Exterior Color
Black
Housing Material
Aluminum die-cast, high-impact flame-retardant polymer, steel
Included Items
Included
Rogue R1E Spot, Seetronic PowerKon power cord, 2x 140D Omega brackets with mounting hardware
