Specifications
Certifications
IP Rating
IP65, outdoor/wet, with pressure equalizing M12 GORE valve
Certifications
CE, MET, FCC, ETL, cULus
Temperature (Ambient)
-4 °F to 113 °F (-20 °C to 45 °C)
Optical
Light Source
134 LEDs (56 quad-color RGBA, 78 WW) 2.7 to 4.32 W, (871 mA), 50,000 hours life expectancy
Color Temperature (Range)
2800 to 6500 K
Color Temperature (at Full)
6528 K
CRI
94.4
CRI (@3200K)
94.4
Beam Angle
59.1°
Field Angle
102.1°
Lumens
25,917
Illuminance (Total)
979 lux @ 5 m
Selectable PWM
600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
Performance
Dimmer
Electronic
Shutter/Strobe
Electronic
Strobe Rate
0 to 30 Hz
Standalone Color Mixing
Yes
Color Temperature Presets
Yes
Dim Modes
4
Dim Curves
4
Built-in Automated Programs
Yes
Control
Control Protocol
Art-Net, sACN, DMX, RDM
Modes/Personalities
10 personalities (1ch, 3ch, 5ch, 7ch, 10ch, 12ch1, 12ch2, 13ch, 16ch, HSV)
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current @ 120 V
600 W, 5.000 A @ 120 V, 60 Hz
Power and Current @ 208 V
583 W, 2.780 A @ 208 V, 60 Hz
Power and Current @ 230 V
581 W, 2.491 A @ 230 V, 50 Hz
Power Linking
2 units @ 120 V; 4 units @ 208 V; 4 units @ 230 V
Connectivity
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
Power Input
Seetronic Powerkon IP65
Power Output
Seetronic Powerkon IP65
Data Connectors
5-pin Seetronic IP65 XLR or Seetronic IP65 etherCON
Cable Length (Power)
5 ft (1.5 m)
Software Update
USB-C
Construction
Dimensions
19.13 x 7.45 x 10.37 in (486 x 189.3 x 263.5 mm)
Weight
20.6 lbs (9.4 kg)
Exterior Color
Black
Housing Material
Aluminum alloy
Included Items
Included
STRIKE Array 2C, Seetronic Powerkon IP65, Omega bracket with mounting hardware
