Specifications
Certifications
IP Rating
IP65, outdoor/wet, with pressure equalizing M12 GORE valve
Certifications
CE, MET, FCC, ETL, cULus
Temperature (Ambient)
−4 °F to 113 °F (−20 °C to 45 °C)
Optical
Light Source
268 LEDs (112 quad-color RGBA, 156 WW), 2.7W to 4.32W, 871 mA, 50,000 hours life expectancy
Lumens
53,481
Illuminance
1979 lux @ 5 m
Beam Angle
59.6°
Field Angle
102.2°
Color Temperature Range
2800 to 6500 K
Color Temperature At Full
5991 K
CRI (@3200K)
94.6
Selectable PWM
600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, 25000Hz
Performance
Dimmer
Electronic
Shutter/Strobe
Electronic
Strobe Rate
0 to 30 Hz
Dim Modes
4
Dim Curves
4
Standalone Color Mixing
Yes
Color Temperature Presets
Yes
Built-In Automated Programs
Yes
Control
Control Protocol
Art-Net, sACN, DMX, RDM
Modes/Personalities
10 personalities (1, 3, 5, 7, 10, 12, 13, 16, 22 or HSV)
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power And Current @ 120V
1180W, 9.92A @ 120V, 60 Hz
Power And Current @ 208V
1150W, 5.60A @ 208V, 60 Hz
Power And Current @ 230V
1140W, 5.02A @ 230V, 50 Hz
Connectivity
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
Power Input
Seetronic Powerkon IP65
Data Connectors
5-pin Seetronic IP65 XLR or Seetronic IP65 etherCON
Cable Length (Power)
5 ft (1.5 m)
Software Update
USB-C
Construction
Dimensions
19.13 x 7.55 x 17.8 in (486 x 191.64 x 452 mm)
Weight
34.4 lbs (15.4 kg)
Exterior Color
Black
Housing Material
Magnesium alloy
Included Items
Included
STRIKE Array 4C, Seetronic Powerkon IP65, Omega bracket with mounting hardware
Compatible Accessories
Accessories
STRIKE Array Flush Bracket, CTC-50HC, CTC-50HCN, SC-08, IP Rated Seetronic Powerkon Extensions, IP Rated DMX cables, IP Rated EtherCon Cables, UPLOAD 03 software uploader
