Chauvet Pro STRIKE V IP65 Motorized Tilting Strobe Wash Hybrid

Chauvet Pro STRIKE V IP65 Motorized Tilting Strobe Wash Hybrid

SoundPro Item: 146912 | Part Number: STRIKEV

$3,766.50
$4,324.00 $3,766.50
Your Price Sold out
MSRP: $4,324.00 | MAP: $3,766.50

Usually ships in 5-7 business days

  • IP65 All-Weather Housing With Pressure-Equalizing GORE Valve For Reliable Outdoor Use
  • Dual RGBW LED Plate Architecture Enables Independent Pixel Mapping Across Two Layers
  • Variable Electronic Frost Filter Shifts Beam Angle Instantly Without Physical Gel Changes
  • Magnetic Stealth Filter Conceals LED Array When Fixture Is Powered Down
  • Motorized Tilt With Repositionable Yoke And Alignment Pins For Seamless Linear Arrays
  • Adjustable PWM Up To 64,000 Hz Ensures Flicker-Free Performance On Camera
  • Failsafe Ethernet Passthrough Maintains Data Chain Through A Power Loss Event
Log in or register for YOUR best price

The Chauvet Pro STRIKE V targets lighting designers and touring production crews who need a single fixture capable of delivering high-impact strobe effects, vibrant multicolor washes, and dynamic pixel mapping in all weather conditions. Its AZ91D magnesium diecast housing and IP65 certification with a pressure-equalizing GORE valve make it a genuine outdoor workhorse — not merely splash-resistant — suited for festivals, stadium shows, and permanent outdoor installs where reliability cannot be compromised.

What separates the STRIKE V from other IP65 blinders and strobes in its class is the combination of two independently controllable LED plates — 24 top-plate RGBW LEDs and 24 bottom-plate RGBW LEDs — behind a variable electronic frost filter that shifts beam angle on command. This dual-layer architecture enables pixel-mapped eye-candy effects, full-field washes, and tight strobe beams from a single fixture footprint, reducing truck pack and rigging complexity on large-scale productions. The motorized 180° tilt range, repositionable yoke, and integrated alignment pins let crews build seamless linear arrays with consistent orientation across any rig.

Networking professionals will appreciate full Art-Net, sACN, RDM, and DMX support, 16-bit master dimmer resolution for silky fade control, adjustable PWM up to 64,000 Hz for camera-safe operation, and failsafe Ethernet passthrough that keeps the data chain intact even during a power loss. An onboard OLED display and USB update port simplify setup and firmware maintenance at the fixture level without additional hardware.

Downloads

View full details

Specifications

Certifications
IP Rating
IP65, temporary outdoor/wet use, with pressure equalizing M12 GORE valve
Certifications
CE, MET, ROHS, FCC
Optical
Light Source (Top Plate)
24 LEDs quad-color RGBW, 6W, 50,000 hours life expectancy
Light Source (Bottom Plate)
24 LEDs quad-color RGBW, 50W, 50,000 hours life expectancy
Beam Angle (Combine)
9.9°
Beam Angle (Dot)
105.7°
Beam Angle (Cell)
9.9°
Beam Angle (w/E-Frost Combine)
50.3°
Beam Angle (w/E-Frost Dot)
103.1°
Beam Angle (w/E-Frost Cell)
46.8°
Field Angle (Combine)
17.6°
Field Angle (Top Plate)
153.1°
Field Angle (Cell)
17.5°
Field Angle (w/E-Frost Combine)
125°
Field Angle (w/E-Frost Dot)
155.6°
Field Angle (w/E-Frost Cell)
117.2°
Lumens (Combine)
19,589
Lumens (Dot)
1,912
Lumens (Cell)
17,127
Lumens (w/E-Frost Combine)
13,406
Lumens (w/E-Frost Dot)
1,633
Lumens (w/E-Frost Cell)
15,769
Illuminance (Combine)
16,779 lux @ 5 m
Illuminance (Dot)
29 lux @ 5 m
Illuminance (Cell)
16,789 lux @ 5 m
Illuminance (w/E-Frost Combine)
539 lux @ 5 m
Illuminance (w/E-Frost Dot)
26 lux @ 5 m
Illuminance (w/E-Frost Cell)
536 lux @ 5 m
Selectable PWM
1000 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25000 Hz, 64,000 Hz
Performance
Tilt
180°
Tilt Range
0° to 180°
Strobe Rate
0 to 30 Hz
Dimmer
Electronic
Shutter/Strobe
Electronic
Dim Modes
4
Standalone Color Mixing
Yes
Built-in Automated Programs
Yes
Electrical
Input Voltage
100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current @ 100V
747 W, 7.54 A @ 100 V, 60 Hz
Power and Current @ 120V
747 W, 6.20 A @ 120 V, 60 Hz
Power and Current @ 208V
719 W, 3.63 A @ 208 V, 60 Hz
Power and Current @ 230V
717 W, 3.28 A @ 230 V, 50 Hz
Power and Current @ 240V
717 W, 3.17 A @ 240 V, 50 Hz
Connectivity
Control Protocol
Art-Net, DMX, RDM, sACN
DMX/ArtNet/sACN Channels (Single Mode)
29, 222, 314
DMX/ArtNet/sACN Channels (Dual Mode Movement)
30
DMX/ArtNet/sACN Channels (Dual Mode Pixels)
144, 192, 240, 288
ArtNet/sACN Multi-Layer Movement
30
ArtNet/sACN Multi-Layer Dot Pixels
72, 96, 120, 144
ArtNet/sACN Multi-Layer Cell Pixels
72, 96, 120, 144
Power Connection
Edison (Local) plug to Seetronic Powerkon IP65
Power Input
Seetronic Powerkon IP65
Data Connectors
5-pin IP65 XLR, Seetronic etherCON IP65
Cable Length (Power)
5 ft (1.5 m)
Construction
Dimensions
16 x 7.3 x 12.2 in (407 x 187.4 x 310 mm)
Weight
36 lbs (16.3 kg)
Exterior Color
Black
Housing Material
AZ91D Magnesium diecast
Environmental
Temperature (Ambient)
14 °F to 113 °F (-10 °C to 45 °C)
Noise Level (Idle)
8.4 dB @ 1 m
Noise Level (Auto)
39.6 dB @ 1 m
Noise Level (Full)
39.5 dB @ 1 m
Noise Level (Silent)
35.0 dB @ 1 m
Noise Level (Max)
34.8 dB @ 1 m
Included Items
Includes
STRIKE V, Seetronic Powerkon IP65 power cord, Omega bracket, Stealth filter
