Specifications
DMX Channels:
4, 15, 18, 34, 66, or 94
DMX Connectors:
3-pin XLR
Light Source:
68 LEDs (quad-color RGB+WW) 0.8W, 50,000 hours life expectancy
Strobe Rate:
0 to 20 Hz
Operating Frequency:
2.412 to 2.48 GHz
Power Linking:
34 units @ 120 V; 47 units @ 230 V
Input Voltage:
100 to 240 VAC, 50/60 Hz (auto-ranging)
Approvals:
CE, FCC
Load Capacity:
132 lb (60 kg)
Cable Length:
5 ft (1.52 m)
Power and Current:
15 W, 0.2 A @ 230 V, 50 Hz
Power and Current:
15 W, 0.3 A @ 120 V, 60 Hz
Weight (pole):
8.2 lbs (3.7 kg)
Weight (base):
34.2 lbs (16 kg)
Weight (combined):
42.4 lbs (19.2 kg)
Threaded inserts (bottom):
M10-1.0 TPI
Threaded insert (top):
M10-1.5 TPI
Pole Height:
4.8 to 8 ft (1.5 to 2.4 m)
Pole Diameter (Top):
1.34 in (34 mm)
1.7 in (44 mm) :
Pole Diameter (Bottom)
2 in (50 mm):
