Specifications
DMX Channels:
3 or 7
DMX Connectors:
3-pin XLR
Light Source:
6 LEDs (tri-color RGB) 4.8 W, (2 A), 50,000 hours life expectancy Strobe Rate: 0 to 20 Hz
Strobe Rate:
0 to 20 Hz
Beam Angle:
17°
Field Angle:
33°
Operating Frequency:
2.4 GHz
Illuminance:
1754 lux @ 2 m
Power Linking:
25 units @ 120 V; 38 units @ 230
Input Voltage:
100 to 240 VAC, 50/60 Hz (auto-ranging)
Weight:
2.2 lb. (1 kg)
Size:
10.4 x 7.6 x 3 in (265 x 218 x 76 mm)
Approvals:
CE, RoHS, FCC
Power and Current:
21 W, 0.3 A @ 120 V, 60 Hz
Power and Current:
21 W, 0.3 A @ 230 V, 50 Hz
Bracket Mounting Hole:
13 mm
Optional Controllers:
IRC6, ILS Command
Bluetooth Version:
4.2
Max Unobstructed Distance:
150 ft (25.7 m)
Max. Output Current:
8 A (25 units @ 120 V) (38 units @ 230 V)
