Specifications
Electrical
Power Supply Input Voltage
100-240V AC nominal
Power Supply Output Voltage
5V; 4A
Charger Input Voltage
5V; 4A
Charge Output
~3W per port
MTBF
300,000 hours calculated
Wireless
Wireless Technology
Wireless PAN, 2.4 GHz
Charging
Charge Ports
4 (BAT70)
Storage Ports
4 (BAT70, no charging)
LED Type
4x RGB per port/battery charging status
Charge Time
2 hours
Dimensions
AC70 Width
3.1"
AC70 Height
4.75"
AC70 Depth
1.75"
AC70 Width (mm)
78.74 mm
AC70 Height (mm)
120.65 mm
AC70 Depth (mm)
44.45 mm
BAT70 Width
1.6"
BAT70 Height
1.8"
BAT70 Depth
0.24"
BAT70 Width (mm)
40.64 mm
BAT70 Height (mm)
45.72 mm
BAT70 Depth (mm)
6.1 mm
Weight
AC70 Weight
0.9 lbs (0.4 kg)
BAT70 Weight
0.11 lbs (0.05 kg)
Environmental
Operating Temperature
32-104 deg F (0-40 deg C)
Storage Temperature
-40-176 deg F (-40-80 deg C)
Humidity
0-95% Non-Condensing
Compatibility
Included Plugs
US, EU, AU, UK, KR
Regulatory Model
AC70
