Specifications
Connectivity
Connector Type
4-pin XLR-M
Compatible Station Connector
4-pin Female (RTS)
Cable Length
5 ft (1.55m)
Headset End Connector
8-pin
Audio
Headphone Type
Closed-back
Headphone Driver
40mm diameter, neodymium magnet, copper-clad aluminum wire voice coil
Headphone Frequency Response
40Hz - 20kHz
Headphone Sensitivity (CC-300)
102dB ±3dB (SPL) /1mW at 1kHz typical
Headphone Impedance (CC-300)
400Ω ±30%; at 1kHz typical
Microphone Element
Dynamic
Microphone Polar Pattern
Hyper-cardioid
Microphone Frequency Response
300Hz - 20kHz
Microphone Open Circuit Sensitivity
-61dB ±3.5dB (0dB=1V/1Pa, at 1kHz, typical)
Microphone Impedance
200Ω ±30%; at 1kHz typical
Weight
Product Weight
0.537 lbs
Headset Weight (CC-300)
8.6oz (245g) without 8-pin cable assembly and M3*18mm screw
Dimensions
Packaging (W x H x D)
4.8" x 13" x 10.43"
Included Items
Headset Bag
Yes
