Community ALC-404D 4-Channel Amplified Loudspeaker Controller With Dante

Community ALC-404D 4-Channel Amplified Loudspeaker Controller With Dante

SoundPro Item: 44441 | Part Number: 911.1353.900

$3,816.00
$3,816.00 $3,816.00
Your Price Sold out
MSRP: $3,816.00 | MAP: $3,816.00

Usually ships in 5-7 business days

  • Factory-Optimized Community Loudspeaker Presets Eliminate Manual DSP Programming
  • Per-Channel Flexible Output Supports Lo-Z, Hi-Z, And Bridged Loads Simultaneously
  • Dante And Analog Inputs Assignable Per Channel With Failover Backup Capability
  • Power Sharing Technology Enables Asymmetric Loading Across All Output Channels
  • Integrated 1024-Tap FIR Linear Phase DSP Removes Need For External Processing Hardware
  • IEC 60849 Compliant Monitoring With GPIO Fault Outputs For Third-Party Integration
  • TAA Compliant For Inclusion In GSA Schedule And Federal Government Bids
Log in or register for YOUR best price

The Community ALC-404D is designed for AV integrators specifying installed sound systems in houses of worship, corporate spaces, education facilities, and public venues where reliable, software-managed loudspeaker control is essential. Each of the four output channels delivers up to 400W and can independently drive low-impedance loads down to 2 ohms, 70V distributed lines, 100V distributed lines, or bridged configurations up to 800W — giving integrators the flexibility to serve mixed-impedance systems from a single rack unit without additional signal processing hardware.

Integration with the ArmonìaPlus System Manager software enables decentralized system tuning, zone management, and real-time remote monitoring from a single interface. Biamp-authored loudspeaker presets for the full Community catalog are built in, delivering factory-optimized EQ, high-pass filters, and multi-stage TruePower limiting tailored to each enclosure. The software automatically calculates and displays power requirements and headroom per output channel, eliminating manual impedance calculations and accelerating system commissioning.

Analog and Dante inputs are assignable per channel in static or failover configurations, supporting straightforward integration into new builds and retrofits alike. IEC 60849 compliant monitoring, per-channel GPIO fault reporting, and TAA compliance make the ALC-404D suitable for mission-critical and government installations. Its 1RU form factor and class-leading thermal efficiency reduce rack space, cooling costs, and long-term operational overhead compared to traditional amplifier-plus-DSP-processor configurations.

Downloads

View full details

Specifications

Certifications
TAA Compliance
Yes
IEC 60849
Compliant
Network Standard
IEEE 802.3u, 100 Mbit/s Fast Ethernet
Dimensions
Height
1.75" (44mm)
Width
17.4" (442mm)
Depth
14.7" (373mm)
Weight
Unit Weight
16.2 lbs (7.3 kg)
Shipping Weight
25 lbs (11.3 kg)
Power
Max Output Power Per Channel @ 8Ω
400 W
Max Output Power Per Channel @ 4Ω
400 W
Max Output Power Per Channel @ 2Ω
400 W
Max Output Power @ 4Ω Bridged
800 W
Max Output Power @ 8Ω Bridged
800 W
Max Output Power @ 100V Hi-Z
400 W
Max Output Power @ 70V Hi-Z
400 W
Max Shared Power (All Channels)
1200 W
Max Unclipped Output Voltage @ 8Ω
80 Vpeak
Maximum Output Current
33 Apeak
Power Supply
Universal regulated switch mode with PFC, SRM
Nominal Voltage
100-240 V @ 50-60 Hz (±10%)
Operating Voltage Range
60-264 V (reduced power below 90 V)
Audio
Output Channels
4 Hi-Z or Lo-Z (bridgeable per channel pair)
Analog Input Channels
4
Dante Input Channels
4
Signal-to-Noise Ratio
>104 dB(A), 20 Hz-20 kHz @ 8Ω
Frequency Response
20 Hz - 20 kHz ±0.5 dB, 1 W @ 8Ω
THD+N
<0.1% (typical <0.05%), 0.1 W to Full Power
IMD
<0.05%, 0.1 W to Full Power
Damping Factor
>500 @ 8Ω, 20 Hz-100 Hz
Crosstalk
-70 dB @ 1 kHz
Input Impedance
20 kΩ balanced
Maximum Input Level
20 dBu
Slew Rate
>50 V/μs @ 8Ω, input filter bypassed
Signal Processing
Sample Rate
24-bit @ 44.1 kHz to 192 kHz
Dynamic Range (DSP)
140 dB, 0.0001% THD+N
Internal Precision
32-bit floating point
Fixed Latency
2.5 ms
A/D Converters
24-bit Tandem @ 48 kHz, 125 dB(A) Dynamic Range, 0.005% THD+N
D/A Converters
24-bit Tandem @ 48 kHz, 117 dB(A) Dynamic Range, 0.003% THD+N
Input Delay
2 s
Output Delay
100 ms
Memory
128 MB RAM + 512 MB flash
Equalizer Types
Raised-cosine, custom FIR, parametric IIR (peaking, hi/lo-shelving, all-pass, band-pass, band-stop, hi/lo-pass)
Crossover Filters
FIR linear phase, Butterworth, Linkwitz-Riley, Bessel; 6 dB/oct to 48 dB/oct (IIR)
Limiters
TruePower, RMS voltage, RMS current, Peak
Environmental
Ambient Operating Temperature
0°-45° C (32°-113° F)
Humidity
0-95% non-condensing
Connectivity
AC Inlet
IEC C20 (20 A max)
Power Cord
Region-specific (US/EU/UK included)
Identifiers
MPN
911.1353.900
