Community R.5COAX66 12-Inch Weather-Resistant Speaker | Color: Black

Community R.5COAX66 12-Inch Weather-Resistant Speaker | Color: Black

SoundPro Item: 62649 | Part Number: 911.1253.900

$1,486.00
$1,486.00 $1,486.00
Your Price Sold out
MSRP: $1,486.00 | MAP: $1,486.00

Usually ships in 5-7 business days

  • Weather-treated drivers and crossovers
  • Included zinc-rich epoxy dual-layer powder-coated steel grille and yoke
  • Weather and UV-resistant rotomolded enclosure with integral mounting points
  • High efficiency, high fidelity and high power passive crossover
Log in or register for YOUR best price

The largest member of the coaxial family, the 12-inch R.5COAX66 features the same high sensitivity and high output as the R.35COAX but with even greater LF extension. Community’s exclusive LF driver and 1-inch exit horn loaded compression driver produce a wide range, smooth musical frequency response with high efficiency, ensuring both high fidelity music reproduction and superb projection of clear intelligible speech with very low distortion.

View full details

Specifications

Dimensions
Height
16" (406.4 mm)
Width
16" (406.4 mm)
Depth
15.94" (404.88 mm)
Weight
Shipping Weight
42 lbs ( 19.1 kg)
Electrical
Minimum Impedance
4.2 ohms @ 9.9 kHz
Audio
Sensitivity (1W/1m)
98 dB SPL (100 Hz to 13 kHz 1/3 octave bands), 97 dB SPL (250 Hz to 4 kHz speech range)
Crossover Frequency
2 kHz
1. Sensitivity
Free field pink noise measurement at 20 ft (6.1 m) at 50% power; extrapolated to 1 meter and an input of 2.83 volts RMS.
Connectivity
Max Input Ratings
200W continuous, 500W program, 40 volts RMS, 89 volts momentary peak
Maximum Output
121 dB SPL / 128 dB SPL (peak)
Input Connection
12 foot (4 m) SJOW #16 gauge
Construction
Enclosure
Rotomolded LLDPE, light grey
Grille
3-layer WeatherStop™, light gray, (Zinc-rich epoxy dual-layer powder coated perforated steel grille, foam, woven poly mesh)
Shipping
Weight
35 lbs (15.9 kg)
General
Loudspeaker Type
2-way, coaxial, weather-resistant, full-range
Operating Range
80 Hz to 18 kHz, 90 Hz to 12.5 kHz (±3.5 dB)
Recommended Power Amplifier
420W to 600W @ 8 ohms
Nominal Impedance
8 ohms
Nominal –6dB Beamwidth
60°H (+20° / -6°, 1.6 kHz to 12.5 kHz), 60°V (+20° / -3°, 1.6 kHz to 12.5 kHz)
Axial Q / DI
15.2 / 11.8, 1.6 kHz to 12.5 kHz
Recommended Signal Processing
60 Hz high pass filter
Drivers
LF 1 x 12”, HF 1 x 1” exit titanium free, Ferrofluid-cooled
Driver Protection
DYNA-TECH protection circuitry
Controls
None
Mounting/Rigging Provisions
(5) 3/8-16 rigging points
Environmental Performance
IEC529 IP54W rating with a minimum 5-degree downward aiming angle
2. Watts
All wattage figures are calculated using the rated nominal impedance.
