Specifications
Dimensions
Dimensions (HxWxD)
25.5x11.3x11.7" (649x287x298mm)
Electrical
Minimum Impedance
3.4 ohms @ 200 Hz
Audio
Frequency Response
90 Hz to 16 kHz (±3 dB)
Sensitivity (1W/1m)
94 dB (100 Hz to 12.5 kHz) free space
Crossover Frequency
1.3 kHz
Connectivity
Max Input Ratings
300W continuous, 750W program 34.6 volts RMS, 69.2 volts momentary peak
Maximum Output
119 dB SPL / 125 dB SPL (peak)
Input Connection
NL4-compatible locking connector with terminal strip in parallel
Construction
Enclosure:
Trapezoidal (22.5° included angle), 18mm, 11-ply cross-laminated birch
Finish
Catalyzed polyester two-part paint, black or white
Grille
Powder coated steel, black or white finish
Shipping
Feature
Weight
General
Loudspeaker Type
Compact two-way, full-range, trapezoidal, vented bass, frequency shaded LF, user rotatable horn
Operating Range
60 Hz to 18 kHz (-10 dB)
Nominal Impedance
4 ohms
Nominal –6dB Beamwidth
90° H x 70° V (in vertical position)
Recommended Signal Processing
70 Hz, 24 dB/octave Butterworth high pass filter
Drivers:
LF 2 x 8-inch cone, HF 1 x 1-inch
Driver Protection
DYNA-TECH protection circuitry
Controls
None
Mounting/Rigging Provisions:
9 x M6 threaded rigging fittings, 4 x M8 for third-party suspension products
Required Accessories
None
Optional Accessories:
CMKIT ceiling mount kit, VB-TILT tilting bracket, VB-VY28 vertical yoke bracket, M6EYBLTKIT 6mm eyebolt kit
