Community VLF208 2x8-Inch Compact Subwoofer | Color: White
Community VLF208 2x8-Inch Compact Subwoofer | Color: White
SoundPro Item: 66493 | Part Number: VLF208W
Usually ships in 5-7 business days
- Low profile design, small footprint
- Designed to work as a traditional subwoofer or in steered bass arrays
- DYNA-TECH™ protection circuitry
- Suitable for in-wall, under-seating, under-stage and other “hidden” LF applications
The VLF208 is a dual 8-inch, no-grille design that can be vertically or horizontally installed under stages, in walls or ceilings, or in other low profile locations. Its extremely low profile enclosure is narrow enough to fit comfortably between wall studs, providing “hidden” LF extension. With a response down to 70 Hz in passive mode or 60 Hz using digital signal processing, the VLF208 can function in pairs as a steered bass array, and is equipped with fly points and four rubber feet with recessed foot mounting locations on two sides. The VLF208 can also be wall-mounted using its specially designed low-profile yoke bracket, the VLF-Y208.
The VLF subwoofers feature a low-profile design that is ideal for theaters, restaurants, auditoria, houses of worship, schools and other venues, with the compact VLF208 and VLF208LV fitting into areas where larger subwoofers are impractical.
- Loudspeaker TypeCompact subwoofer
- Operating Range
- 55 Hz to 400 Hz
- 60 Hz to 160 Hz (±1 dB) processed
- Max Input Ratings
- 300W continuous, 750W program, 4 ohms
- 35 volts RMS, 77 volts momentary peak
- Recommended Power Amplifier630W to 900W @ 4 ohms
- Sensitivity (1W/1m)95 dB SPL (63 Hz to 160 Hz 1/3 octave bands)
- Maximum Output120 dB SPL / 127 dB SPL (peak)
- Nominal Impedance4 ohms
- Minimum Impedance4.8 ohms @ 130 Hz
- Nominal –6dB Beamwidth360°H x 180°V
- Axial Q / DI1/0, 60 Hz to 160 Hz
- Recommended Signal Processing55 Hz high pass filter, 48 dB/Oct Drivers: LF (2) 8"
- Driver ProtectionDYNA-TECH™
- Input Connection
- (1) NL4-compatible locking connector
- (1) 2 conductor barrier strip
- Enclosure11-ply cross-laminated birch
- FinishBlack or white paint finish
- Mounting/Rigging Provisions(8) M10 hang points
- Required AccessoriesDigital signal processor
- Dimensions (HxWxD)8.25x21.75x13" (210x552x330 mm)
- Weight42 lbs (19.1 kg)
- Notes
- 1. Sensitivity: Half-space pink noise measurement at 4 ft (1.2 m) at 25% power; extrapolated to 1 meter and an input of 2 volts RMS.
- 2. Watts: All wattage figures are calculated using the rated nominal impedance.
