Specifications
Frequency Response:
Omnidirectional: 20 Hz to 20 kHz Directional: 30 Hz to 15 kHz
Operating Current:
500 uA
Operating Voltage:
1 to 2 Volts
Power Supply Voltage:
+3V with 2.7 kOhm load +5V with 6.8 kOhm load +9V with 15 kOhm load
Weight:
0.07 oz (2 g)
Sensitivity:
Omnidirectional W5 (no band): 7.0 mV/Pascal Omnidirectional W6 (blue band): 2.0 mV/Pascal Omnidirectional W7 (purple band): 0.7 mV/Pascal Directional W5 (no band): 6.0 mV/Pascal Directional W6 (blue band): 1.9 mV/Pascal Directional W7 (purple band): 0.6 mV/Pascal
Equivalent Acoustic Noise:
W5: 24 dBA W6: 29 dBA W7: 39 dBA
Overload Sound Level:
Omnidirectional W5: 120 dB SPL Omnidirectional W6: 130 dBA SPL Omnidirectional W7: 140 dBA SPL Directional W5: 125 dBA SPL Directional W6: 135 dBA SPL Directional W7: 145 dBA SPL
Cable Length:
5 Feet
