Specifications
Frequency Response:
Omnidirectional: 20 Hz to 20 kHz Directional: 50 Hz to 20 kHz
Overload Sound Level:
150 dB SPL at 1% THD
Ouput Impedance:
600 Ohms +/- 2% balanced, transformerless. Will drive load impedance without distortion at full rated SPL.
Equivalent Acoustic Noise:
Omnidirectional: 25 dBA Directional: 29 dBA
Power Requirements:
6V to 50V Phantom at 4mA. Voltage below 24V wil result in reduced overload SPL.
Sensitivity:
1.4 mV/Pascal
Dimensions:
9/32" x 7/16" x 5/32" (7mm x 10.5mm x 3.5mm) excluding cable strain relief.
