Specifications
Dimensions
Capsule Dimensions
0.23" x 0.18" (5.8mm x 4.6mm)
Cable Length
5 Feet
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
Capsule Weight
0.012 oz (0.34 g)
Shipping Weight
0.75 lbs
Electrical
Power Requirements
Wireless: 3V to 12V at 200 uA Phantom: 9V to 48V (4mA at 48V)
Phantom
9V to 48V (4mA at 48V)
Audio
Frequency Response
20 Hz to 20 kHz
Polar Pattern
Omnidirectional
Sensitivity
W4 (no band): 12.0 mV/Pascal (-38 dB re 1V/Pa) W5 (red band): 4.0 mV/Pascal (-48 dB re 1V/Pa)
Equivalent Acoustic Noise
24 dBA
Overload Sound Level
Wireless: 140 dBA SPL (5V, red band) Phantom: 150 dBA SPL (48V, red band)
Connectivity
Connector Type
TA4F (SL)
Gain
Standard Gain
Construction
Cable Diameter
2mm
Cable Material
Duramax Aramid-Reinforced Cable
Color
White
Compatibility
Shure
BLX1, FP1, PG1, SLX1, UC1, ULX1, UR1, UR1M
Carvin
UBP1000, UX16-BP, UXBP16
Trantec
S4.4-BTX, S5.3-BTX, S5.5-BTX
JTS
E-6TB, E-7TB(D), IN264TB, IN64TB, PG-36BG2, PT-850B, PT-850BD, PT900B, PT-920B, PT-920BG, PT-920BGmi, PT-920Bmi, PT-950, PT-950Bmi, RU-850LTB, RU-850TB, RU-988TB, RU-G3TB, UF-10TB, UF-20TB
Beyerdynamic
TG 1000 (gray switch), TG 100B (gray switch)
Shipping
Weight
0.012 oz (0.34 g)
General
Transducer Type
Condenser
