Specifications
Dimensions
Capsule Dimensions
0.23" x 0.18" (5.8mm x 4.6mm)
Cable Length
5'
Weight
Capsule Weight
0.012 oz (0.34 g)
Shipping Weight
0.75 lbs
Electrical
Power Requirements (Wireless)
3V to 12V at 200 uA
Power Requirements (Phantom)
9V to 48V (4mA at 48V)
Phantom
9V to 48V (4mA at 48V)
Audio
Frequency Response
20 Hz to 20 kHz
Polar Pattern
Omnidirectional
Sensitivity (W4, no band)
12.0 mV/Pascal (-38 dB re 1V/Pa)
Sensitivity (W5, red band)
4.0 mV/Pascal (-48 dB re 1V/Pa)
Equivalent Acoustic Noise
24 dBA
Overload Sound Level (Wireless)
140 dBA SPL (5V, red band)
Overload Sound Level (Phantom)
150 dBA SPL (48V, red band)
Connectivity
Connector
Hirose 4 pin (AT)
Construction
Cable Diameter
2mm
Cable Material
Duramax Aramid-Reinforced
Color
Black
Compatibility
Gain
Mid Gain
Compatible Models
Audio Technica ATW-T1801, ATW-T201, ATW-T210, ATW-T210a, ATW-T27, ATW-T31, ATW-T310, ATW-T310b, ATW-T51
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
0.012 oz (0.34 g)
General
Transducer Type
Condenser
