Specifications
Dimensions
Capsule Dimensions
0.23" x 0.18" (5.8mm x 4.6mm)
Weight
Capsule Weight
0.012 oz (0.34 g)
Shipping Weight
0.75 lb
Electrical
Power Requirements (Wireless)
3V to 12V at 200 uA
Power Requirements (Phantom)
9V to 48V (4mA at 48V)
Phantom
9V to 48V (4mA at 48V)
Audio
Frequency Response
20 Hz to 20 kHz
Polar Pattern
Omnidirectional
Sensitivity (W4, no band)
12.0 mV/Pascal (-38 dB re 1V/Pa)
Sensitivity (W5, red band)
4.0 mV/Pascal (-48 dB re 1V/Pa)
Equivalent Acoustic Noise
24 dBA
Overload Sound Level (Wireless)
140 dBA SPL (5V, red band)
Overload Sound Level (Phantom)
150 dBA SPL (48V, red band)
Connectivity
Connector
3.5mm locking
Construction
Cable Length
5 Feet
Cable Diameter
2mm Duramax Aramid-Reinforced Cable
Compatibility
Gain
Mid gain for theatre head miking
Color
Black
Sennheiser Compatible Models
SK 100 G1, SK 100 G2, SK 100 G3, SK 100 G4, SK 1093, SK 20, SK 300 G1, SK 300 G2, SK 300 G3, SK 300 G4, SK 500 G1, SK 500 G2, SK 500 G3, SK 500 G4, SK AVX, SK D1, SK-XSW, SL Bodypack DW, XSW-D TX35
Audio 2000's Compatible Models
AWX6030M
Shipping
Shipping Dimensions
9.125 in x 5.125 in x 1.375 in
Weight
0.012 oz (0.34 g)
General
Transducer Type
Condenser
