Specifications
Dimensions
Capsule Dimensions
0.23" x 0.18" (5.8mm x 4.6mm)
Cable Length
5 Feet
Weight
Capsule Weight
0.012 oz (0.34 g)
Electrical
Power Requirements (Wireless)
3V to 12V at 200 uA
Power Requirements (Phantom)
9V to 48V (4mA at 48V)
Phantom
9V to 48V (4mA at 48V)
Audio
Frequency Response
20 Hz to 20 kHz
Polar Pattern
Omnidirectional
Sensitivity (W4, no band)
12.0 mV/Pascal (-38 dB re 1V/Pa)
Sensitivity (W5, red band)
4.0 mV/Pascal (-48 dB re 1V/Pa)
Equivalent Acoustic Noise
24 dBA
Overload Sound Level (Wireless)
140 dBA SPL (5V, red band)
Overload Sound Level (Phantom)
150 dBA SPL (48V, red band)
Construction
Cable Diameter
2mm Duramax Aramid-Reinforced Cable
Color
Tan
Connector
Hirose 4 pin
Gain
Mid Gain
Compatibility
Compatible Models
Audio Technica ATW-T1801, ATW-T201, ATW-T210, ATW-T210a, ATW-T27, ATW-T31, ATW-T310, ATW-T310b, ATW-T51
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Shipping Weight
0.75 lbs
Weight
0.012 oz (0.34 g)
General
Transducer Type
Condenser
