Specifications
Weight
Mic Weight
0.07 oz (2 g)
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response
20 Hz to 20 kHz
Polar Pattern
Omnidirectional
Sensitivity
7.0 mV/Pa (-43 dB re 1V/Pa)
Equivalent Acoustic Noise
29 dBA
Overload Sound Level
130 dB SPL
Connectivity
Connector
3.5mm locking
Detachability
Fixed/Non-Detachable
Construction
Cable Length
5 Feet
Cable Diameter
1.25mm
Cable Type
Aramid-Reinforced
Compatibility
Sennheiser
SK 100 G1, SK 100 G2, SK 100 G3, SK 100 G4, SK 1093, SK 20, SK 300 G1, SK 300 G2, SK 300 G3, SK 300 G4, SK 500 G1, SK 500 G2, SK 500 G3, SK 500 G4, SK AVX, SK D1, SK-XSW, SL Bodypack DW, XSW-D TX35
Audio 2000's
AWX6030M
Gemini
UHF-6000BP
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Shipping Weight
0.75 lbs
Weight
0.07 oz (2 g)
Identifiers
Color
Tan
Gain
Mid Gain
General
Transducer Type
Condenser
W4 (standard, Gray band)
16.0 mV/Pa (-36 dB re 1V/Pa)
W5 (mid, Red band)
7.0 mV/Pa (-43 dB re 1V/Pa)
W6 (low, Blue band)
2.0 mV/Pa (-54 dB re 1V/Pa)
W4
24 dBA
W5
29 dBA
W6
39 dBA
