Specifications
Weight
Product Weight
0.07 oz (2 g)
Shipping Weight
0.75 lbs
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity (Directional W6, Blue Band)
1.9 mV/Pascal
Equivalent Acoustic Noise (W6)
29 dBA
Overload Sound Level (Directional W6)
135 dBA SPL
Polar Pattern
Directional
Connectivity
Cable Length
5 Feet
Compatibility
Shure AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Construction
Cable Diameter
1mm
Cable Type
Aramid-Reinforced
Boom Flexibility
Very Flexible
Color
Black
Connector
TA4F (AX)
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
0.07 oz (2 g)
General
Omnidirectional
20 Hz to 20 kHz
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W7
145 dBA SPL
