Specifications
Weight
Product Weight
0.07 oz (2 g)
Audio
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity W6 Directional (blue band)
1.9 mV/Pascal
Equivalent Acoustic Noise W6
29 dBA
Overload Sound Level W6 Directional
135 dBA SPL
Performance
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Connectivity
Connector
TA4F (AX)
Cable Length
5'
Compatibility
Shure: AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Construction
Boom Flexibility
Very flexible
Cable Diameter
2mm Duramax Aramid-Reinforced
Polar Pattern
Directional
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Shipping Weight
0.75 lbs
Weight
0.07 oz (2 g)
Identifiers
Color
Black
General
Omnidirectional
20 Hz to 20 kHz
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
Directional W7
145 dBA SPL
