Specifications
Weight
Product Weight
0.07 oz (2 g)
Electrical
Operating Voltage
1 to 2 Volts
Operating Current
500 uA
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Polar Pattern
Omnidirectional
Frequency Response (Omnidirectional)
20 Hz to 20 kHz
Sensitivity (W7, Purple Band)
0.7 mV/Pascal (Omnidirectional)
Overload Sound Level (W7, Omnidirectional)
140 dBA SPL
Equivalent Acoustic Noise (W7)
39 dBA
Connectivity
Connector Type
TA4F (AX)
Cable Diameter
2mm
Cable Length
5'
Construction
Cable Material
Duramax Aramid-Reinforced
Boom Flexibility
Very Flexible
Color
Black
Compatibility
Compatible Transmitters
Shure: AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Shipping Weight
0.75 lbs
Weight
0.07 oz (2 g)
Identifiers
MPN
E6IOW7B2AX
General
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
Directional W7
145 dBA SPL
