Specifications
Weight
Mic Weight
0.07 oz (2 g)
Shipping Weight
0.75 lbs
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Polar Pattern
Omnidirectional
Frequency Response (Omnidirectional)
20 Hz to 20 kHz
Sensitivity (W6, Blue Band)
2.0 mV/Pascal
Equivalent Acoustic Noise (W6)
29 dBA
Overload Sound Level (Omnidirectional W6)
130 dBA SPL
Connectivity
Connector Type
TA4F (AX)
Cable Length
5 Feet
Construction
Boom Style
Classic/Springy
Cable Diameter
2mm
Cable Material
Duramax Aramid-Reinforced
Color
Tan
Compatibility
Compatible Transmitters
Shure AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
0.07 oz (2 g)
General
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W7
145 dBA SPL
