Specifications
Weight
Product Weight
0.07 oz (2 g)
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity W5 Directional (no band)
6.0 mV/Pascal
Sensitivity W6 Directional (blue band)
1.9 mV/Pascal
Sensitivity W7 Directional (purple band)
0.6 mV/Pascal
Equivalent Acoustic Noise W5
24 dBA
Equivalent Acoustic Noise W6
29 dBA
Equivalent Acoustic Noise W7
39 dBA
Overload Sound Level W5 Directional
125 dBA SPL
Overload Sound Level W6 Directional
135 dBA SPL
Overload Sound Level W7 Directional
145 dBA SPL
Connectivity
Connector Type
3.5mm locking (SR)
Construction
Cable Diameter
1mm
Cable Type
Aramid-Reinforced
Cable Length
5 Feet
Color
Light Beige
Boom Type
Flexible front section and springy ear section
Pickup Pattern
Directional
Compatibility
Sennheiser
SK 100 G1, SK 100 G2, SK 100 G3, SK 100 G4, SK 1093, SK 20, SK 300 G1, SK 300 G2, SK 300 G3, SK 300 G4, SK 500 G1, SK 500 G2, SK 500 G3, SK 500 G4, SK AVX, SK D1, SK-XSW, SL Bodypack DW, XSW-D TX35
Audio 2000's
AWX6030M
Gemini
UHF-6000BP
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Shipping Weight
0.75 lbs
Weight
0.07 oz (2 g)
General
Omnidirectional
20 Hz to 20 kHz
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
Directional W7
145 dBA SPL
