Specifications
Weight
Mic Weight
0.07 oz (2 g)
Shipping Weight
1 lb
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity - Directional W5 (No Band)
6.0 mV/Pascal
Sensitivity - Directional W6 (Blue Band)
1.9 mV/Pascal
Sensitivity - Directional W7 (Purple Band)
0.6 mV/Pascal
Equivalent Acoustic Noise - W5
24 dBA
Equivalent Acoustic Noise - W6
29 dBA
Equivalent Acoustic Noise - W7
39 dBA
Overload Sound Level - Directional W5
125 dBA SPL
Overload Sound Level - Directional W6
135 dBA SPL
Overload Sound Level - Directional W7
145 dBA SPL
Polar Patterns
Directional, Omnidirectional
Connectivity
Cable Length
5 Feet
Compatible Transmitters
Shure AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Construction
Cable Diameter
1.25 mm
Cable Material
Aramid-Reinforced
Boom Flexibility
Classic/Springy
Color
Tan
Connector
TA4F
Pickup Pattern
Directional
Sensitivity Level
Standard Gain
Shipping
Shipping Dimensions
9.75" x 7.625" x 3.25"
Weight
0.07 oz (2 g)
Identifiers
MPN
H6DW5TAX
General
Transducer Type
Condenser
Omnidirectional
20 Hz to 20 kHz
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
