Specifications
Weight
Mic Weight
0.07 oz (2 g)
Shipping Weight
1 lb
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity W5 Directional (No Band)
6.0 mV/Pascal
Sensitivity W6 Directional (Blue Band)
1.9 mV/Pascal
Sensitivity W7 Directional (Purple Band)
0.6 mV/Pascal
Equivalent Acoustic Noise W5
24 dBA
Equivalent Acoustic Noise W6
29 dBA
Equivalent Acoustic Noise W7
39 dBA
Overload Sound Level W5 Directional
125 dBA SPL
Overload Sound Level W6 Directional
135 dBA SPL
Overload Sound Level W7 Directional
145 dBA SPL
Polar Patterns
Directional, Omnidirectional
Construction
Capsule Diameter
0.1" (2.5 mm)
Cable Diameter
1.25 mm
Cable Reinforcement
Aramid strength members and engineered alloys
Cable Length
5 Feet
Flexibility
Classic/springy boom
Color
Light Beige
Connector
TA4F (SL)
Pattern
Directional
Shipping
Shipping Dimensions
9.75" x 7.625" x 3.25"
Weight
0.07 oz (2 g)
General
Transducer Type
Condenser
Omnidirectional
20 Hz to 20 kHz
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
Directional W7
145 dBA SPL
