Specifications
Weight
Mic Weight
0.07 oz (2 g)
Shipping Weight
1 lb
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity W5 (No Band, Directional)
6.0 mV/Pascal
Sensitivity W6 (Blue Band, Directional)
1.9 mV/Pascal
Sensitivity W7 (Purple Band, Directional)
0.6 mV/Pascal
Equivalent Acoustic Noise W7
39 dBA
Overload Sound Level W7 (Directional)
145 dBA SPL
Polar Patterns
Directional, Omnidirectional
Connectivity
Compatible Systems
Shure AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Construction
Cable Diameter
1.25 mm
Cable Material
Aramid-Reinforced
Boom Flexibility
Classic/Springy
Connector Type
TA4F
Color
Light Beige
Cable Length
5 Feet
Shipping
Shipping Dimensions
9.75" x 7.625" x 3.25"
Weight
0.07 oz (2 g)
Identifiers
MPN
H6DW7LAX
General
Transducer Type
Condenser
Omnidirectional
20 Hz to 20 kHz
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
Directional W7
145 dBA SPL
