Specifications
Weight
Mic Weight
0.07 oz (2 g)
Shipping Weight
1 lb
Electrical
Operating Current
500 uA
Operating Voltage
1 to 2 Volts
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Power Supply Voltage
+3V with 2.7 kOhm load, +5V with 6.8 kOhm load, +9V with 15 kOhm load
Audio
Polar Pattern
Omnidirectional
Frequency Response (Omnidirectional)
20 Hz to 20 kHz
Frequency Response (Directional)
30 Hz to 15 kHz
Sensitivity W5 (no band)
7.0 mV/Pascal
Sensitivity W6 (blue band)
2.0 mV/Pascal
Sensitivity W7 (purple band)
0.7 mV/Pascal
Equivalent Acoustic Noise W5
24 dBA
Equivalent Acoustic Noise W6
29 dBA
Equivalent Acoustic Noise W7
39 dBA
Overload Sound Level W5
120 dB SPL
Overload Sound Level W6
130 dBA SPL
Overload Sound Level W7
140 dBA SPL
Polar Patterns
Directional, Omnidirectional
Connectivity
Connector Type
Hirose 4 pin (AT)
Construction
Color
Tan
Cable Diameter
1.25mm
Cable Reinforcement
Aramid-Reinforced
Cable Length
5 Feet
Boom Flexibility
Classic/springy boom
Compatibility
Brand/Model Compatibility
Audio Technica: ATW-T1801, ATW-T201, ATW-T210, ATW-T210a, ATW-T27, ATW-T31, ATW-T310, ATW-T310b, ATW-T51
Shipping
Shipping Dimensions
9.75" x 7.625" x 3.25"
Weight
0.07 oz (2 g)
Identifiers
MPN
H6OW5TAT
General
Transducer Type
Condenser
Omnidirectional W5 (no band)
7.0 mV/Pascal
Omnidirectional W6 (blue band)
2.0 mV/Pascal
Omnidirectional W7 (purple band)
0.7 mV/Pascal
Directional W5 (no band)
6.0 mV/Pascal
Directional W6 (blue band)
1.9 mV/Pascal
Directional W7 (purple band)
0.6 mV/Pascal
W5
24 dBA
W6
29 dBA
W7
39 dBA
Omnidirectional W5
120 dB SPL
Omnidirectional W6
130 dBA SPL
Omnidirectional W7
140 dBA SPL
Directional W5
125 dBA SPL
Directional W6
135 dBA SPL
Directional W7
145 dBA SPL
