Specifications
Audio
Frequency Response (Cardioid)
50 Hz to 20 kHz
Equivalent Acoustic Noise (Cardioid)
29 dBA
Sensitivity
1.4 mV/Pascal
Overload Sound Level
150 dB SPL at 1% THD
Output Impedance
600 Ohms +/- 2% balanced, transformerless
Polar Pattern
Cardioid
Electrical
Power Requirements
6V to 50V Phantom at 4mA
Construction
Cable Diameter
2mm Duramax Aramid-Reinforced Cable
Capsule Dimensions
9/32" x 7/16" x 5/32" (7mm x 10.5mm x 3.5mm) excluding cable strain relief
Color
Black
Connectivity
Connector
TA4F
Compatibility
Brand/Model Compatibility
Shure: AD1, ADX1, AXT100TA4F, GLXD1, PGXD1, QLXD1, ULXD1
Shipping
Shipping Dimensions
9.125 in x 5.125 in x 1.375 in
Weight
0.75 lbs
