Specifications
Audio
Frequency Response
Directional: 50 Hz to 20 kHz
Polar Pattern
Hypercardioid
Equivalent Acoustic Noise
29 dBA
Sensitivity
1.4 mV/Pascal
Sensitivity Gain
High
Overload Sound Level
150 dB SPL at 1% THD
Output Impedance
600 Ohms +/- 2% balanced, transformerless
Electrical
Power Requirements
6V to 50V Phantom at 4mA
Dimensions
Capsule Dimensions
9/32" x 7/16" x 5/32" (7mm x 10.5mm x 3.5mm) excluding cable strain relief
Construction
Cable Diameter
2mm
Cable Type
Duramax Aramid-Reinforced
Color
Black
Connectivity
Connector
TA4F
Compatibility
Shure
BLX1, FP1, PG1, SLX1, UC1, ULX1, UR1, UR1M
Carvin
UBP1000, UX16-BP, UXBP16
JTS
E-6TB, E-7TB(D), IN264TB, IN64TB, PG-36BG2, PT-850B, PT-850BD, PT900B, PT-920B, PT-920BG, PT-920BGmi, PT-920Bmi, PT-950, PT-950Bmi, RU-850LTB, RU-850TB, RU-988TB, RU-G3TB, UF-10TB, UF-20TB
Trantec
S4.4-BTX, S5.3-BTX, S5.5-BTX
Beyerdynamic
TG 1000 (gray switch), TG 100B (gray switch)
Shipping
Shipping Dimensions
9.125" x 5.125" x 1.375"
Weight
0.75 lbs
