Specifications
Audio
Frequency Response (Omnidirectional)
20 Hz to 20 kHz
Frequency Response (Directional)
50 Hz to 20 kHz
Overload Sound Level
150 dB SPL at 1% THD
Equivalent Acoustic Noise (Omnidirectional)
25 dBA
Equivalent Acoustic Noise (Directional)
29 dBA
Sensitivity
1.4 mV/Pascal
Sensitivity Gain
High Gain
Output Impedance
600 Ohms +/- 2% balanced, transformerless
Electrical
Power Requirements
6V to 50V Phantom at 4mA
Connectivity
Connector
XLR3 Male
Cable Diameter
2mm Duramax Aramid-Reinforced Cable
Hardwired Compatibility
Hardwired/XLR
Construction
Color
Black
Polar Pattern
Hypercardioid
Dimensions
Capsule Dimensions
9/32" x 7/16" x 5/32" (7mm x 10.5mm x 3.5mm) excluding cable strain relief
Weight
Product Weight
0.75 lbs
Shipping
Shipping Dimensions
9.125 in x 5.125 in x 1.375 in
