Specifications
General
Brand
Danley
MPN
DTS20
Product Type
Subwoofer
Performance
Operating Frequency Range
18 Hz- 100 Hz -3dB 16 Hz -10dB
Continuous Output
122 dB SPL
Peak Output
128 dB SPL
Sensitivity
95 dB SPL (2.83 Volts into rated Z, at 1 meter) measured in half space
Magnitude Response
18 Hz – 100 Hz
Configuration
Driver Complement
one 12″ long excursion woofer
Rated Impedance
8 Ohms
Power Rating
500 W continuous 1,000 W program
Physical
Dimensions
87.5 x 18 x 20 inches
Weight
220 lbs
