Specifications
General
Brand
Danley
MPN
SH60
Product Type
Loudspeaker
Performance
Coverage Pattern
60˚ horizontal 60˚ vertical
Operating Frequency Range
48 Hz – 18 kHz +/- 3 dB; 41 Hz – 24 kHz -10dB
Continuous Output
127 dB SPL
Peak Output
133 dB SPL
Sensitivity
100 dB SPL (2.83 Volts into rated Z, at 1 meter) measured in whole space
Magnitude Response
48 Hz -18 kHz
Rated Impedance
4 Ohms
Power Rating
1000 Watts Cont. 4000 Watts Peak
Drivers
Driver Complement
Low 2 x 12″ Mid 6 x 4″ High 1 x 1″
Physical
Dimensions
28 x 28 x 22 inches
Weight
127 lbs
