Danley SM60F-I-EDM Compact Full-Range Loudspeaker 60° X 60° | Install Version | Black

Danley SM60F-I-EDM Compact Full-Range Loudspeaker 60° X 60° | Install Version | Black

SoundPro Item: 204275 | Part Number: SM60F-I-EDM

$5,899.50
$6,210.00 $5,899.50
Your Price Sold out
MSRP: $6,210.00 | MAP: $5,899.50

Usually ships in 5-7 business days

  • 60° x 60° pattern supports focused coverage
  • Modular array capability adds deployment flexibility
  • Compact enclosure fits space-sensitive AV designs
  • 125 dB continuous output handles demanding rooms
  • Dual 8" LF drivers support full-range performance
  • Touring or installed versions suit different workflows
Log in or register for YOUR best price

The Danley SM60F is a compact full-range loudspeaker built for professional audio systems that need controlled coverage and strong output from a relatively small enclosure. Its 60° horizontal by 60° vertical pattern makes it well suited for applications where consistency matters, including speech reinforcement, music playback, and tightly managed coverage zones. With modular array capability, the SM60F also gives system designers added flexibility when a single enclosure is not enough.

This model combines dual 8-inch low-frequency drivers with a 5-inch high-frequency section in a compact format that supports both portable production workflows and permanent installations. Danley specifies operating response from 66 Hz to 24 kHz within ±4 dB, with extension to 52 Hz to 26 kHz at -10 dB, making it a practical choice where broad bandwidth is required from a single box. High sensitivity and substantial output help it perform in demanding environments while preserving headroom.

Available in touring and installed versions, the SM60F fits projects that value deployment flexibility as much as acoustic performance. For integrators, it offers a compact option for coverage-focused designs. For live production teams, it delivers a manageable form factor with professional output capability. Buyers considering a high-performance point-source loudspeaker for precise pattern control and scalable deployment will find the SM60F a strong candidate.

View full details

Specifications

General
Brand
Danley
MPN
SM60F
Category
Full-range loudspeaker
Coverage
Coverage Pattern
60˚ horizontal 60˚ vertical
Performance
Operating Frequency Range
66 Hz – 24 kHz +/- 4 dB; 52 Hz – 26 kHz – 10dB
Continuous Output
125 dB SPL
Peak Output
131 dB SPL
Sensitivity
99 dB (2.83 Volts into rated Z, at 1 meter) measured in free space
Magnitude Response
66 Hz – 24 kHz
Rated Impedance
4 Ohms
Power Rating
800 Watts Cont. 3200 Watts Peak
Drivers
Driver Complement
Lows 2 x 8″ Highs 1 x 5″
Physical
Dimensions
20.85 x 20.85 x 16.3 inches
Weight
50lbs
