Specifications
Performance
coverage Pattern
80° Conical
operating frequency range
45Hz-17kHz +/- 3dB 39Hz-23kHz – 10dB
continuous output
Mid/High 128 dB SPL Low 135 dB SPL
peak output
Mid/High 134 dB SPL Low 141 dB SPL
sensitivity
Mid/High 102 dB SPL Low 106 dB SPL measured in wholespace at 1M @ 2.83V input
Rated Impedance
Mid/High 8 Ohms Low 2 Ohms
Power Rating
Mid/High 400 Watts Cont. 1600 Watts Peak Low 3400 Watts Cont. 13,600 Watts Peak
Configuration
driver complement
1 x 12″ coaxial 2 x 15″ woofers
Physical
dimensions
45 x 26 x 28 inches
weight
215 lbs
