DAS Audio 15004759 4-Channel Matrix Amplifier With DSP and Dante

DAS Audio 15004759 4-Channel Matrix Amplifier With DSP and Dante

SoundPro Item: 207662 | Part Number: 15004759

$3,417.00
$3,417.00 $3,417.00
Your Price Sold out
MSRP: $3,417.00 | MAP: $3,417.00

Usually ships in 5-7 business days

  • Full Matrix Architecture With Priority Management For Multi-Zone Routing Control
  • Alma And ALMAweb Remote Control Via IP, Wi-Fi, And Bluetooth
  • Built-In Ethernet Switch Enables Daisy-Chain Networking Without External Switches
  • Dual Analog Inputs Configurable As Mic Inputs With Phantom Power
  • GPIO Interface Allows Integration With Third-Party Control Systems Via ALMA
  • Over 100 Global Presets And 200 Output Channel Presets Including DAS Audio Configs
  • Class D Output Stage With Comprehensive Amplifier Protection Suite
Log in or register for YOUR best price

The DAS Audio INTEGRAL-MA3004 is engineered for systems integrators and installation contractors deploying permanent, scalable audio systems in commercial, corporate, or public venue environments. With four amplified output channels and a fully integrated DSP matrix engine, it consolidates routing, processing, and amplification into a single 2U rack unit — reducing rack space and simplifying system architecture without sacrificing flexibility.

Its 4x4 Dante/AES67 digital audio network allows seamless integration into IP-based audio infrastructures, while the built-in Ethernet switch supports daisy-chain topologies without requiring external networking hardware. Dual-mode analog inputs — switchable to microphone with phantom power — alongside GPIO for third-party control and OSC protocol support make this amplifier a practical hub in both simple and complex multi-zone installations. Compatibility with both low-impedance (4–8 ohm) and high-impedance (70V/100V) systems means it adapts to a broad range of speaker deployments without additional transformers or interface hardware.

ALMA software and ALMAweb over IP provide full remote configuration, monitoring, and preset recall from any networked device, while onboard Wi-Fi and Bluetooth enable wireless access without a wired connection to the host machine. With over 100 global presets and 200 output channel presets — including factory-optimized DAS Audio speaker configurations — commissioning and recall across multiple zones is fast and repeatable. The front-panel OLED display with rotary controls ensures local operation remains accessible for on-site technicians when network access is unavailable.

Downloads

View full details

Specifications

Output Power
Amplifier Channels
4
Power at 8 Ohms
4 x 400 W
Power at 8 Ohms Bridged
2 x 1500 W
Power at 4 Ohms
4 x 750 W
Power at 4 Ohms Bridged
2 x 1500 W
Power at 2 Ohms
4 x 750 W
Power at 100V
2 x 1500 W
Power at 70V
2 x 1200 W
Audio
Amplifier Output Circuitry
Class D
Frequency Response
20 Hz–30 kHz (+0 / -0.5 dB)
Input Sensitivity
+20 dBu
Max Input Level
+22 dBu
Voltage Gain
17.5 dB
Sampling Rate
48 kHz
DSP
Analog Input Channels
4
Analog Output Channels
4
Dante Input Channels
4
Dante Output Channels
4
AD Converters
24 Bit @ 48 kHz, 118 dB Dynamic Range
DA Converters
24 Bit @ 48 kHz, 118 dB Dynamic Range
Internal Precision
32 Bit / 64 Bit Double Precision
Latency
1 ms
Delay
50 ms per input / 120 ms per output
Equalizer
Bell, Lo/Hi-Shelving, HOS
Crossover
Linkwitz-Riley, Butterworth, Bessel
High and Low Pass Filters
Up to 48 dB/oct
Limiters
RMS, Peak
Load Monitoring
Yes
Connectivity
Analog Audio Input Connectors
2 x 3.5 mm Pitch Terminal Block
Dante Digital In/Out Connectors
2 x RJ45 Fast Ethernet
Speaker Output Connector
Terminal Block
AC Input Connector
IEC
Controls & Display
Display
OLED 1.54"
Controls
Power On/Off, Navigation Knobs
LED Indicators
On, Comms, Signal, Protect
Cooling
Side Right-to-Left
Amplifier Protections
Short Circuit, DC Output, Temperature, Over/Under Voltage
Power
Power Supply
Universal Mains Switch Mode
Operating Range
90–250 VAC
Current Draw 230V / 115V
3.0 A / 6.0 A
Dimensions
Product Height
3.5"
Product Width
19.0"
Product Depth
8.2"
Weight
Net Weight
11.5 lbs
Shipping
Carton Height
6.7"
Carton Width
20.7"
Carton Depth
12.4"
Shipping Weight
13.2 lbs
