Specifications
Dimensions
Dimensions (HxWxD)
13.2" x 25.6" x 17.7"
Audio
Max SPL at 1m
130 dB
Input Impedance
20k ohms
Input Sensitivity
1.95V (+8dBu)
Audio Signal Input Connector
2x female XLR
Audio Signal Loop Thru Connector
2x male XLR
Connectivity
Input Type
balanced
AUX Input
1x3.5mm mini jack
AC Output Connector
powerCON NAC3MPB
Construction
Construction
birch plywood with ISO-flex black paint
Shipping
Weight
43 pounds (19.5 kg)
General
Frequency Range (-10dB)
60Hz - 20kHz
Horizontal Coverage
80°
Vertical Coverage
50°
Continuous
500W
Peak
1000W
Control
DAScontrol™
115V
1.1 A/2.2 A
230V
a:1:{i:0;s:5:”1.1 A”;}
LF Driver
12MI4
Horn/waveguide
BC-85
Drivers
HF Driver
M-34
