Specifications
Dimensions
Dimensions (HxWxD)
42.1" x 21.5" x 26.6"
Audio
Max SPL at 1m
140 dB
Input Impedance
20k ohms
Input Sensitivity
1.95V (+8dBu)
Audio Signal Input Connector
2x female XLR
Audio Signal Loop Thru Connector
2x male XLR
Connectivity
Input Type
balanced
AC Output Connector
powerCON NAC3MPB
Construction
Construction
birch plywood with ISO-flex black paint
Shipping
Weight
133.4 pounds (60.5 kg)
General
Frequency Range (-10dB)
35Hz - 125Hz (variable LPF)
Continuous
1600W
Peak
3200W
115V
-6.0 A
230V
a:0:{}
LF Driver
18FW4
